Electrical Requirements | |
Amperage | 15 Amps. |
Frequency | 60 Hz. |
Voltage | 120 V. |
Circuit Amps @ 120VAC | 15 |
Type | |
VentilationType | Updraft |
Performance | |
Duct Outlet Size | 2-6" round or 1-10" Round |
CFM (Vertical, Round) | 1200 (2 - 600 cfm) |
Duct Outlet Type | Round |
Sones (Vertical, Round) | 8.0 |
Lighting / Controls | |
Number of Light Settings | 1 |
Number of Speeds | 3 |
Number of Cooktop Lights | 2 |
Cooktop Light Type | Halogen |
Control Type | Slider |
Ventilation Features | |
Grease Filter | Dishwasher Safe Aluminum Mesh |
Dimensions | |
Product Depth | 22 Inches |
Product Height | 13 13/16 Inches |
Product Width | 47 13/16 Inches |
Shipping Weight | 55 LB |
Depth: | 22 in. |
Height: | 13 13/16 in |
Width: | 47 13/16 in. |
Features | |
---|---|
Charcoal Filter: | Yes |
Convertible to Re-Circulating Installs: | Yes |
Duct Type: | Round |
Fan Speeds: | 3 |
Heavy Duty Grease Filters: | Yes |
Twin Blower: | Yes |
Type: | Wall Mount |
Venting Style: | Vent |
Washable Filters: | Yes |
Lighting: | 6 Halogen |
Duct Size: | 6 in. Round |
Controls | |
Control Type: | Infinite Slide |
Capacity | |
Maximum Exhaust Capacity: | 1200 CFM |
Electrical | |
Details: | 15 Ampere, 120 Volts, 60 Hertz (1/second), USE COPPER WIRE ONLY. GROUNDED CIRCUIT IS REQUIRED. A TIME-DELAY FUSE OR CIRCUIT BREAKER AND SEPARATE CIRCUIT IS RECOMMENDED. |
