- Our extra-large 12" element gives you space for larger pots and pans.
- Cooktops are approved for installation above any of our Single Electric Wall Ovens.
- Alerts you when your cooktop may be too warm to touch.
- Select options or control cooking temperature with our easy to use controls.
- Alerts you when your cooktop is on.
Garantie du fabricant: 1 an
General Specifications | |
Product Weight (lbs) | 40 |
Power Type | Electric |
Size | 30'' |
Installation Type | Drop-In |
Collection | Frigidaire |
Exterior Dimensions | |
Depth | 21-3/8" |
Height | 3" |
Width | 30-3/4" |
Certifications & Approvals | |
ADA Compliant | No |
Electrical Specifications | |
Amps @ 240 Volts | 32.9 / 28.4 |
Connected Load (kW Rating) @ 240V | 7.9 / 5.9 |
Minimum Circuit Required (Amps) | 30A |
Power Supply Connection Location | Right Rear |
Voltage Rating | 240V / 208V, 60Hz |
Controls | |
Control Location | Right Side |
Cooktop Specifications | |
Cooking Surface | Black Ceramic Glass |
Hot-Surface Indicator Light | Yes |
Knob Color | Black |
Knob Type | Plastic |
Left Front | 12" - 2,700 Watts |
Left Rear | 6" - 1,200 Watts |
Right Front | 9" - 2,500 Watts |
Right Rear | 7" - 1,500 Watts |
