- Self-clean allows you to spare yourself from the trouble and effort it takes to scrub the oven interior
- Remarkably large oven interior is ideal for holidays, dinner parties and everyday family cooking
- Matte-finish, connected cooktop grates provide a sturdy, uninterrupted surface that allows pots and pans to move easily
- Deep recessed cooktop keeps spills, and everything else, contained in one area that's easy to wipe clean
- Ideal for pancakes, bacon, sandwiches and more, the large non-stick griddle is convenient and easy to clean
- This powerful element instantly supplies the intense heat need for boiling, saute ing and stir frying
Garantie du fabricant: 1 an
Configuration | Range with Storage Drawer |
Ignition System | Electronic |
Oven Cleaning Type | Self-Clean |
Temperature Management System | TrueTemp™ System |
Cleaning Time | Variable |
Cooktop Burner Type | Sealed |
Cooktop Surface | Color-Matched Deep Recessed One-Piece Upswept Porcelain-Enamel |
All-Purpose Burners | (1) 9,100 BTU/850 BTU |
Center Oval Burner | (1) 6,000 BTU |
Cooktop Burner Grate Features | Continuous Grates Dishwasher Safe |
Cooktop Burner Grate Material | Heavy Cast |
High Output Burner | (1) 11,000 BTU/150F degree simmer |
Power Boil Burner | (1) 17,000 BTU |
Precise Simmer Burner | (1) 5,000 BTU/140F degree simmer |
Valves (Degree of Turn) | 270 |
Control Type | Digital Temperature Display Electronic Oven Controls QuickSet IV |
Oven Control Features | Audible Preheat Signal Automatic Oven Timer (Time Bake) Auto Oven Shut-Off Auto Self Clean Certified Sabbath Mode Control Lock Capability Delay Bake Option (Time Bake) Delay Clean Option Electronic Clock and Timer Hi / Low Broil In-Oven Broiling Oven Cycle Light Oven "ON" Light Self-Clean Cool Down Time Display |
Cooking Technology | Traditional |
Fuel Type | Natural Gas (factory set) |
Leveling System | 4 Leveling Legs |
Oven Rack Features | 2 Oven Racks 6 Embossed Rack Positions |
Scratch-Resistant Backguard | Porcelain-Enameled |
Oven Interior | Oven Interior Light |
Griddle | Non-Stick |
CAPACITY | |
Total Capacity (cubic feet) | 5.0 cu ft |
APPEARANCE | |
Color Appearance | Stainless Steel |
Control Knobs | Designer-Style |
Cooktop Burner Grate Color | Black Matte |
Frameless Oven Door(s) | Stainless Steel |
Handle | Stainless Steel Sculptured |
Oven Door Features | Big Hearth Oven Window |
WEIGHTS & DIMENSIONS | |
Approximate Shipping Weight | 225 lb |
Cabinet Width | 30 in |
Net Weight | 205 lb |
Oven Interior Dimensions (W x H x D) (in.) | 24 x 19 x 19 |
Overall Depth | 26 5/8 in |
Overall Height | 47 in |
Height to Cooking Surface (in.) | 36 1/4 +/- 1/4 |
Overall Width | 30 in |
Depth with Door Open 90° | 46 3/8 in |
POWER / RATINGS | |
Oven/Broiler BTU Rating - LP (000's BTU's) | 16.0 Oven / 12.0 Broiler |
Oven/Broiler BTU Rating - Nat. Gas (000's BTU's) | 16.0 Oven / 13.5 Broiler |
Top Burner BTU Rating - Nat. Gas (000's BTU's) | (1) 17.0; (1) 11.0, (1) 9.1; (1) 6.0; (1) 5.0 |
Volts/Hertz/Amps | 120V; 60Hz; 5A |
ACCESSORIES | |
LP Conversion Kit | Included |
WARRANTY | |
Parts Warranty | Limited 1-year entire appliance |
Labor Warranty | Limited 1-year entire appliance |
Warranty Notes | See written warranty for full details |
