Garantie du fabricant: 1 an
CAPACITY | |
Total Capacity (cubic feet) | 4.8 cu ft |
Unit Capacity | Extra-Large Oven |
FEATURES | |
Cooktop Burner Type | Sealed |
Scratch-Resistant Backguard | Porcelain-Enameled |
One-Piece Drip Pans | Optional Accessory |
High Output Burner | (2) 12000/1000 BTU |
Precise Simmer Burner | (1) 5000/600 BTU |
Leveling System | 4 Leveling Legs |
Interior Oven Light | Yes |
Oven Control Features | Audible Preheat Signal Auto Oven Shut-Off Auto Self Clean Electronic Clock and Timer Self-Clean Cool Down Time Display Oven Cycle Light Oven "ON" Light Certified Sabbath Mode Control Lock Capability Hi / Low Broil In-Oven Broiling |
Temperature Management System | TrueTemp System |
Ignition System | Electronic |
Oven Cleaning Type | Self-Clean |
Fuel Type | Natural Gas (factory set) |
Configuration | Range with Storage Drawer |
All-Purpose Burners | (1) 9500/850 BTU |
Cooktop Surface | One-Piece Upswept Porcelain-Enamel |
Valves (Degree of Turn) | 270 |
Cooktop Burner Grate Features | Continuous Grates |
Oven Rack Features | 2 Oven Racks 6 Embossed Rack Positions |
Cooktop Burner Grate Material | Cast |
Control Type | Digital Temperature Display Electronic Oven Controls QuickSet III SmartLogic Controls |
APPEARANCE | |
Handle | Stainless Steel Sculptured |
Color Appearance | Stainless Steel |
Oven Door Features | Big Hearth-Shaped Oven Window |
Frameless Oven Door(s) | Stainless Steel |
WEIGHTS & DIMENSIONS | |
Approximate Shipping Weight | 213 lb |
Depth With Oven Door Open 90 Degrees (in.) | 46-3/8 |
Cabinet Width | 30 in |
Oven Interior Dimensions (W x H x D) (in.) | 24 x 18-1/2 x 19 |
Net Weight (lbs.) | 193 lb |
Overall Height | 46 1/8 in |
Overall Width | 30 in |
Height to Cooking Surface (in.) | 36 +/- 1/4 |
Overall Depth | 26 1/4 in |
POWER / RATINGS | |
Volts/Hertz/Amps | 120V; 60Hz; 5A |
Top Burner BTU Rating - Nat. Gas (000's BTU's) | (2) 12.0; (1) 9.5; (1) 5.0 |
Electrical Requirements | 120V; 60Hz; 5A |
Top Burner BTU Rating - LP (000's BTU's) | (2) 11.0; (1) 9.1; (1) 5.0 |
Oven/Broiler BTU Rating - Nat. Gas (000's BTU's) | 16.0 Oven / 13.5 Broiler |
ACCESSORIES | |
LP Conversion Kit | Included |
WARRANTY | |
Warranty Notes | For models produced on or after January 1, 2006 See written warranty for full details |
Labor Warranty | Limited 1-year entire appliance |
Parts Warranty | Limited 1-year entire appliance |
