- Enough room to cook an entire meal at once
- Smooth surface and rounded corners make clean-up quick and easy
- Allows for low, even heat distribution that is ideal for delicate foods and sauces
- All-purpose burner delivers two levels of BTU output to accommodate virtually all your cooking needs
- Burner elements are sealed to the cooktop to keep foods and liquid contained on the cooktop, making cleaning painless
- Convenient clock and timer helps you coordinate meal preparation and cooking
Garantie du fabricant: 1 an
CAPACITY | |
Total Capacity (cubic feet) | 4.8 cu ft |
FEATURES | |
Ignition System | Electronic |
Oven Cleaning Type | Standard Clean |
Cooktop Burner Type | Sealed |
Cooktop Surface | One-Piece Upswept Porcelain-Enamel |
All-Purpose Burners | (2) 9,500/850 BTU |
Cooktop Burner Grate Material | Deluxe Porcelain Steel Square |
High Output Burner | (1) 12,000/1,000 BTU |
Precise Simmer Burner | (1) 5,000/600 BTU |
Valves (Degree of Turn) | 270 |
Control Type | Electronic Oven Controls QuickSet III |
Broiler Pan and Grid | Yes |
Clock and Minute Timer | Electronic |
Fuel Type | Natural Gas (factory set) |
Leveling System | 4 Leveling Legs |
One-Piece Drip Pans | Grey Porcelain-Enameled |
Oven Rack Features | 2 Oven Racks 6 Embossed Rack Positions |
Scratch-Resistant Backguard | Porcelain-Enameled |
Slide - Out Broiler Drawer | Yes |
Oven Interior | Oven Interior Light |
APPEARANCE | |
Color Appearance | Black on Black |
Control Knobs | Designer-Style |
Cooktop Burner Grate Color | Black |
Frameless Oven Door(s) | Black Glass |
Handle | Color-Matched Gloss |
Oven Door Features | Big Hearth Oven Window |
WEIGHTS & DIMENSIONS | |
Approximate Shipping Weight | 180 lb |
Cabinet Width | 30 in |
Net Weight | 160 lb |
Oven Interior Dimensions (W x H x D) (in.) | 24 x 18-1/2 x 19 |
Overall Depth | 26 1/4 in |
Overall Height | 46 1/2 in |
Overall Width | 30 in |
POWER / RATINGS | |
Oven/Broiler BTU Rating - LP (000's BTU's) | 16.5 |
Oven/Broiler BTU Rating - Nat. Gas (000's BTU's) | 18.0 |
Top Burner BTU Rating - LP (000's BTU's) | (1) 11.0; (2) 9.5; (1) 5.0 |
Top Burner BTU Rating - Nat. Gas (000's BTU's) | (1) 12.0; (2) 9.5; (1) 5.0 |
Volts/Hertz/Amps | 120V; 60Hz; 5A |
ACCESSORIES | |
LP Conversion Kit | Included |
WARRANTY | |
Parts Warranty | Limited 1-year entire appliance |
Labor Warranty | Limited 1-year entire appliance |
Warranty Notes | See written warranty for full details |
