- Contains spills for quick and easy cleaning
- Burner elements are sealed to the cooktop to keep foods and liquid contained on the cooktop, making cleaning painless
- This 12,000 (or 11,000) BTU burner element provides the high heat ideal for frying or saute ing and fast heat-up
- Allows for low, even heat distribution that is ideal for delicate foods and sauces
- Cooktop grates provide a sturdy, uninterrupted surface that allows pots and pans to move easily
Garantie du fabricant: 1 an
Cooktop Burner Type | 4 Sealed |
Cooktop Surface | Deep Porcelain-Enamel |
Ignition System | Electronic |
All-Purpose Burners | (2) 9,500 BTU/150F degree simmer |
High Output Burner | (1) 11,000 BTU/150F degree simmer |
Precise Simmer Burner | (1) 5,000 BTU/140F degree simmer |
Control Location | Right Side |
Cooktop Burner Grate Features | Continuous Grates Dishwasher Safe |
Cooktop Burner Grate Material | Medium Cast |
Dishwasher Safe Knobs | Yes |
Fuel Type | Natural Gas (factory set) |
APPEARANCE | |
Color Appearance | Black on Black |
Claims & Certifications | |
ADA Compliant | |
America at Work: Product Assembled in the U.S.A. | |
WEIGHTS & DIMENSIONS | |
Approximate Shipping Weight | 44 lb |
Cabinet Width | 30 in |
Cutout Dimensions (Width x Depth) (In.) | 28-1/2 x 19-5/8 |
Net Weight | 39 lb |
Overall Depth | 21 in |
Overall Height | 3 3/16 in |
Overall Width | 30 in |
POWER / RATINGS | |
Burner BTU Ratings (000's/BTU) - LP Gas | (1) 10.0; (2) 9.1; (1)5.0 |
Burner BTU Ratings (000's/BTU) - Natural Gas | (1) 11.0; (2) 9.5; (1) 5.0 |
Volts/Hertz/Amps | 120V; 60Hz; 5A |
ACCESSORIES | |
LP Conversion Kit | Included |
WARRANTY | |
Parts Warranty | Limited 1-year entire appliance |
Labor Warranty | Limited 1-year entire appliance |
Warranty Notes | For models produced on or after January 1, 2006 See written warranty for full details |
