Garantie du fabricant: 1 an
FEATURES | |
Control Location | Upfront |
Cooktop Burner Type | 5 Sealed |
Ignition System | Electronic |
Fuel Type | Natural Gas (factory set) |
All-Purpose Burners | (2) 9500 BTU |
One-Piece Drip Pans | Porcelain-Enamel |
High Output Burner | 12,000 BTU |
Cooktop Surface | Tempered Glass |
Cooktop Burner Grate Features | Dishwasher Safe |
Precise Simmer Burner | (2) 5000 BTU/140F degree simmer |
Cooktop Burner Grate Material | Deluxe Cast |
APPEARANCE | |
Color Appearance | Stainless Steel |
WEIGHTS & DIMENSIONS | |
Approximate Shipping Weight | 38 lb |
Cabinet Width | 36 in |
Net Weight (lbs.) | 33 lb |
Overall Height | 3 1/16 in |
Overall Width | 36 1/8 in |
Space Required Below Cooktop (In.) | 7/16 |
Overall Depth | 21 1/4 in |
Cutout Dimensions (Width x Depth) (In.) | 33-7/8 x 19-1/8 |
POWER / RATINGS | |
Volts/Hertz/Amps | 120V; 60Hz; 5A |
Burner BTU Ratings (000's/BTU) - LP Gas | (1) 11.0; (2) 9.5; (2) 5.0 |
Burner BTU Ratings (000's/BTU) - Natural Gas | (1) 12.0; (2) 9.5; (2) 5.0 |
ACCESSORIES | |
LP Conversion Kit | Included |
WARRANTY | |
Warranty Notes | For models produced on or after January 1, 2006 See written warranty for full details |
Labor Warranty | Limited 1-year entire appliance |
Parts Warranty | Limited 1-year entire appliance |
