- Allows the cooktop to be customized to suit individual cooking styles and tastes. Modules sold separately
- Shipped with unit (right bay) offers a range of temperature settings for cooking versatility
- Powerful exhaust system effectively pulls smoke and steam out of the kitchen
- Powerful variable speed exhaust system that effectively pulls smoke and vapors out of the kitchen
- Adhere to cooktop to help contain spills and make cleaning quick and easy
- Provide a flat, sturdy surface allowing easy movement of pans between burners
Garantie du fabricant: 1 an
Cooktop Burner Type | 2 Sealed, 10,000 BTU |
Cooktop Surface | Deep Porcelain-Enamel |
Ignition System | Electronic |
Accepts Modules | Left Side Only |
Component Style | Downdraft Vent |
Configuration | Dual Modular - Both sides accept optional modules |
Control Type | Infinite Heat Rotary |
Control Location | Upfront |
Downdraft Exhaust (CFM) | 400 |
Variable Speed Fan | 3 Speeds - Hi/Med/Low |
Cooktop Burner Grate Features | Continuous Grates Dishwasher Safe |
Dishwasher Safe Knobs | Yes |
Fuel Type | Natural Gas (factory set) |
Gas Grill Module (sold separately) | JXGG90L (left side only) |
Griddle Module (sold separately) | JXGL90L (left side only, requires grill module (JXGG90L) to operate) |
LP Convertible | Yes, Kit Included |
Mix or Match Component Capability | Yes |
Optional Blower Mount Capabilities | Back or Straight Down |
Removable Grease Filter(s) | Yes |
Style | Downdraft |
Two Burner Gas Module (right side included) | JXGB90W (left side sold separately) |
Valves (Degree of Turn) | 270 |
APPEARANCE | |
Control Panel Color | White |
Color Appearance | White on White |
Cooktop Burner Grate Color | Black Matte |
claims & certifications | |
ADA Compliant | |
WEIGHTS & DIMENSIONS | |
Approximate Shipping Weight | 74 lb |
Cabinet Width | 30 in |
Net Weight | 64 lb |
Overall Depth | 21 3/4 in |
Overall Height | 18 1/2 in |
Overall Width | 30 in |
Space Required Below Cooktop | 6 in |
POWER / RATINGS | |
Burner BTU Ratings (000's/BTU) - LP Gas | (1) 9.1 |
Burner BTU Ratings (000's/BTU) - Natural Gas | (1) 10.0 |
Griddle BTU Rating (000's/BTU) - LP Gas | (1) 9.1 |
Griddle BTU Rating (000's/BTU) - Natural Gas | (1) 10.0 |
Grill BTU Rating (000's/BTU) - LP Gas | (1) 9.1 |
Grill BTU Rating (000's/BTU) - Natural Gas | (1) 10.0 |
Volts/Hertz/Amps | 120v; 60Hz; 15A |
ACCESSORIES | |
LP Conversion Kit | Included |
WARRANTY | |
Parts Warranty | Limited 1-year entire appliance |
Labor Warranty | Limited 1-year entire appliance |
Warranty Notes | For models produced on or after January 1, 2006 See written warranty for full details |
