- Self-clean allows you to spare yourself from the trouble and effort it takes to scrub the oven interior
- Allows for low, even heat distribution that is ideal for delicate foods and sauces
- Burner elements are sealed to the cooktop to keep foods and liquid contained on the cooktop, making cleaning painless
- This 12,000 (or 11,000) BTU burner element provides the high heat ideal for frying or saute ?ing and fast heat-up
- Electronic pads on the control panel are easy to operate with just a touch
- Connected cooktop grates provide a sturdy, uninterrupted surface that allows pots and pans to move easily
Garantie du fabricant: 1 an
Configuration | Range with Storage Drawer |
Ignition System | Electronic |
Oven Cleaning Type | Self-Clean |
Cleaning Time | Variable |
Oven Rack Features | 2 Oven Racks |
Temperature Management System | TrueTemp System |
Cooktop Burner Type | Sealed |
Cooktop Surface | Porcelain-Enamel |
All-Purpose Burners | (1) 9,500 BTU/150F degree simmer |
High Output Burner | (2) 12,000/1,250 BTU |
Precise Simmer Burner | (1) 5,000 BTU/140F degree simmer |
Oven Control Features | Audible Preheat Signal Auto Oven Shut-Off with Override Certified Sabbath Mode Control Lock Capability Delay Bake Option (Time Bake) Electronic Clock & Kitchen Timer In-Oven Broiling Mis-Wire Detection Start Pad Temperature Display |
Cooktop Burner Grate Features | Continuous Grates |
Cooktop Burner Grate Material | Medium Cast |
Dishwasher Safe Knobs | Yes |
Valves (Degree of Turn) | 270 |
Fuel Type | Natural Gas (factory set) |
Leveling System | 4 Leveling Legs |
Oven Interior | Hidden Bake Oven Interior Light |
CAPACITY | |
Total Capacity (cubic feet) | 4.1 cu ft |
APPEARANCE | |
Color Appearance | White on White |
Control Knobs | Plastic |
Cooktop Burner Grate Color | Grey |
Frameless Oven Door(s) | White Glass |
Handle | Color-Matched |
Installation | Flush Appearance |
Oven Door Features | Big ClearView Oven Window |
claims & certifications | |
ADA Compliant | |
WEIGHTS & DIMENSIONS | |
Approximate Shipping Weight | 188 lb |
Cabinet Opening | 30 in |
Cabinet Width | 30 in |
Net Weight | 167 lb |
Overall Depth | 26 5/8 in |
Overall Height | 35 1/2 in |
Overall Width | 31 1/4 in |
POWER / RATINGS | |
Oven/Broiler BTU Rating - LP (000's BTU's) | 15.0 Oven / 12.0 Broiler |
Oven/Broiler BTU Rating - Nat. Gas (000's BTU's) | 15.0 Oven / 12.0 Broiler |
Top Burner BTU Rating - LP (000's BTU's) | (2) 11.0; (1) 9.1; (1) 5.0 |
Top Burner BTU Rating - Nat. Gas (000's BTU's) | (2) 12.0; (1) 9.5; (1) 5.0 |
Volts/Hertz/Amps | 120V; 60Hz; 5A |
ACCESSORIES | |
LP Conversion Kit | Included |
Optional Backguard | JXS37WW (White) |
Trim Kit - Body Side | JXS77WW (White) |
Trim Kit - Lower | JXS56WW (White) |
Trim Kit - Vertical Side | JXS86WW (White) |
WARRANTY | |
Parts Warranty | Limited 1-year entire appliance |
Labor Warranty | Limited 1-year entire appliance |
Warranty Notes | See written warranty for full details |
