Garantie du fabricant: 1 an
FEATURES | |
Control Location | Front Center |
Cooktop Burner Type | Smoothtop 5 Ribbon |
6"/9" Dual Heating Element | 1 Ribbon (1000/2500W) |
8" Heating Element (s) | 1 Ribbon (2000 watt) |
Indicator Lights | 5 Hot Surface Surface Element "ON" |
Cooktop Control Features | Child Lock |
Style | Smoothtop |
6" Heating Element (s) | 2 Ribbon (1200W) |
Cooktop Surface | Patterned Black on Black Glass Ceramic |
7" Heating Element(s) | 1 Ribbon (1500W) |
Dishwasher Safe Knobs | Yes |
Control Type | Infinite Heat Rotary |
APPEARANCE | |
Color Appearance | Black on Black |
Frameless | Yes |
WEIGHTS & DIMENSIONS | |
Approximate Shipping Weight | 40 lb |
Cabinet Width | 36 in |
Net Weight (lbs.) | 35 lb |
Overall Height | 3 1/4 in |
Cooktop Size (in.) | 36 in |
Overall Width | 36 in |
Overall Depth | 20 7/8 in |
Cutout Dimensions (Width x Depth) (In.) | 33-7/8 x 19-1/8 |
POWER / RATINGS | |
Amp Rating at 208V | 40 |
Amp Rating at 240V | 40 |
KW Rating at 240V | 8.4 |
KW Rating at 208V | 6.3 |
ACCESSORIES | |
Optional Flush Mount Kit | JXFLMBB (Black - use with black glass cooktops with a white, bisque or black pattern) |
WARRANTY | |
Warranty Notes | For models produced on or after January 1, 2006 See written warranty for full details |
Labor Warranty | Limited 1-year entire appliance |
Parts Warranty | Limited 1-year entire appliance |
