Garantie du fabricant: 1 an
FEATURES | |
Control Location | Front Center |
Cooktop Burner Type | 5 Ribbon |
6"/9" Dual Heating Element | 1 Ribbon (2500W) |
Indicator Lights | 4 Hot Surface Surface Element "ON" |
Style | Downdraft |
Bridge Element | 800 Watt (Links 7" Elements) |
6" Heating Element (s) | 1 Ribbon (1500W) |
Downdraft Exhaust (CFM) | 400 |
Cooktop Surface | Glass Ceramic True White Glass Ceramic |
7" Heating Element(s) | 2 Ribbon (1800W) |
Downdraft Vent Fan Speeds | 3 |
Control Type | Infinite Heat Rotary |
APPEARANCE | |
Color Appearance | True White |
Frameless | Yes |
WEIGHTS & DIMENSIONS | |
Approximate Shipping Weight | 72 lb |
Cabinet Width | 30 in |
Net Weight (lbs.) | 57 lb |
Overall Height | 2 in |
Cooktop Size (in.) | 30 in |
Overall Width | 29 7/8 in |
Overall Depth | 21 7/8 in |
POWER / RATINGS | |
Amp Rating at 208V | 40 |
Amp Rating at 240V | 40 |
KW Rating at 240V | 8.8 |
KW Rating at 208V | 6.7 |
WARRANTY | |
Warranty Notes | For models produced on or after January 1, 2006 See written warranty for full details |
Labor Warranty | Limited 1-year entire appliance |
Parts Warranty | Limited 1-year entire appliance Limited 5-year glass cooktop/radiant surface units |
