- Accepts optional Select-Top modules (left bay)
- Shipped with unit (right bay), offers multiple temperature settings
- Powerful exhaust system effectively pulls smoke and steam out of the kitchen
- Keep spillover contained on cooktop, making cleaning quick and easy
Garantie du fabricant: 1 an
APPEARANCE | |
Control Panel Color | Black |
Color Appearance | Black on Black |
Cooktop Burner Grate Color | Black Gloss |
FEATURES | |
Cooktop Burner Type | 2 Sealed |
Cooktop Surface | Deep Porcelain-Enamel |
Ignition System | Electronic |
Accepts Modules | Left and Right Side |
Component Style | Downdraft Vent |
Burner - Right Front | 10,000 BTU |
Burner - Right Rear | 10,000 BTU |
Configuration | Dual Modular - Both sides accept optional modules |
Control Type | Infinite Heat Rotary |
Control Location | Upfront |
CFM/ Sones Rating | 390/ 6.5 (High Speed) |
Variable Speed Fan | 3 Speeds - Hi/Med/Low |
Cooktop Burner Grate Features | Continuous GratesDishwasher Safe |
Dishwasher Safe Knobs | Yes |
Fuel Type | Natural Gas (factory set) |
Gas Grill Module (sold separately) | JXGG90L (left side only) |
Griddle Module (sold separately) | JXGL90L (left side only, requires grill module (JXGG90L) to operate) |
LP Convertible | Yes, Kit Included |
Mix or Match Component Capability | Yes |
Optional Blower Mount Capabilities | Back or Straight Down |
Removable Grease Filter(s) | Yes |
Two Burner Gas Module (right side included) | JXGB90B (left side sold separately) |
Valves (Degree of Turn) | 270 |
POWER / RATINGS | |
Burner BTU Ratings (000's/BTU) - LP Gas | (1) 9.1 |
Burner BTU Ratings (000's/BTU) - Natural Gas | (1) 10.0 |
Griddle BTU Rating (000's/BTU) - LP Gas | (1) 9.1 |
Griddle BTU Rating (000's/BTU) - Natural Gas | (1) 10.0 |
Grill BTU Rating (000's/BTU) - LP Gas | (1) 9.1 |
Grill BTU Rating (000's/BTU) - Natural Gas | (1) 10.0 |
Volts/Hertz/Amps | 120v; 60Hz; 15A |
WARRANTY | |
Parts Warranty | Limited 1-year entire appliance |
Labor Warranty | Limited 1-year entire appliance |
Warranty Notes | See written warranty for full details |
WEIGHTS & DIMENSIONS | |
Approximate Shipping Weight | 74.0 |
Cabinet Width | 30.0 |
Net Weight | 64.0 |
Overall Depth | 21.75 |
Overall Height | 18.5 |
Overall Width | 30.0 |
Space Required Below Cooktop | 6.0 |
