- Digital buttons are precise and easy-to-use for great results
- Accurate control ensures even heating and less temperature variation
- Know exactly how much time you have left before enjoying delicious foods
- Element shuts off if no pan is detected, giving you additional peace of mind
- Dual-size element automatically adjusts settings to fit the size of the pan
- Two heating elements in one allows you to choose a heating area for your cookware
Garantie du fabricant: 1 an
Cooktop Surface | Black Patterned Glass Ceramic with Stainless Steel Trim |
Cooktop Burner Type | Smoothtop 4 Ribbon |
Style | Smoothtop |
5"/8" Dual Heating Element | 1 Ribbon (1,000/2,200W) |
6" Heating Element(s) | 1 Ribbon w/ Warmer (1,200W) |
6"/9" Dual Heating Element | 1 Ribbon (1,000/2,500W) |
7" Heating Element(s) | 1 Ribbon (1,500W) |
Control Type | Electronic Touch |
Cooktop Control Features | Child Lock Pan Presence Sensor Pan Size Sensor |
Control Location | Right Side |
Indicator Lights | 4 Hot Surface Surface Element "ON" |
Kitchen Timer | Yes |
APPEARANCE | |
Color Appearance | Stainless Steel |
claims & certifications | |
ADA Compliant | |
WEIGHTS & DIMENSIONS | |
Approximate Shipping Weight | 41 lb |
Cabinet Width | 30 in |
Cooktop Size | 30 in |
Cutout Dimensions (Width x Depth) (In.) | 28-1/2 x 19-5/8 |
Net Weight | 36 lb |
Overall Depth | 21 1/2 in |
Overall Height | 3 1/4 in |
Overall Width | 29 7/8 in |
POWER / RATINGS | |
Amp Rating at 208V | 30 |
Amp Rating at 240V | 40 |
KW Rating at 208V | 5.6 |
KW Rating at 240V | 7.4 |
WARRANTY | |
Parts Warranty | Limited 1-year entire appliance Limited 5-year glass cooktop/radiant surface units |
Labor Warranty | Limited 1-year entire appliance |
Warranty Notes | For models produced on or after January 1, 2006 See written warranty for full details |
