Garantie du fabricant: 1 an
Electrical Requirements | |
Frequency | 60 Hz. |
Voltage | 240/208 V. |
Circuit Amps @ 240VAC | 40 Amps. |
Performance | |
Element Type | Smoothtop |
Fuel Type | Electric |
Number of Elements | 5 |
Cooktop Features | |
Center Front Element Size (Inches) | 8.000 |
Center Front Element Type | Single-Ring Round plus Bridge |
Center Rear Element Size (Inches) | 8 |
Center Rear Element Type | Radiant Single |
Left Front Element Size (Inches) | 10 |
Left Front Element Type | Triple-Ring Round |
Left Rear Element Size (Inches) | 7 |
Left Rear Element Type | Single-Ring Round |
Right Rear Element Size (Inches) | 7 |
Right Rear Element Type | Single-Ring Round |
All Element Power Off | Yes |
Keep Warm | Yes |
Melt & Hold | Yes |
Simmer | Yes |
Design | |
Hot Surface Indicator | Yes |
Cooktop Design | Ceramic Glass |
Glass Pattern | Watermark |
Cooktop Controls | Electronic |
Specifications | |
Center Rear Element Wattage (@240V) | 1800 |
Left Front Element Wattage (@240V) | 2500 |
Left Rear Element Wattage (@240V) | 1200 |
Right Rear Element Wattage (@240V) | 1500 |
Center Front Element Wattage (@240V) | 1800/700 |
Dimensions | |
Product Depth | 21 5/16 Inches |
Product Height | 3 1/16 Inches |
Product Width | 36 5/16 Inches |
