Garantie du fabricant: 1 an
Electrical Requirements | |
Amperage | 15 Amps. |
Frequency | 60 Hz. |
Voltage | 120 V. |
Circuit Amps @ 120VAC | 15 |
Type | |
VentilationType | Updraft |
Performance | |
Duct Outlet Size | 6" |
Duct Outlet Type | Round |
CFM (Vertical, Round) | 600 |
Blower Type | Pro Motor |
Sones (Vertical, Round) | 7.0 |
Lighting / Controls | |
Number of Light Settings | 1 |
Number of Speeds | 3 |
Number of Cooktop Lights | 3 |
Cooktop Light Type | Halogen |
Control Type | Slider |
Ventilation Features | |
Grease Filter | Dishwasher Safe Aluminum Mesh |
Dimensions | |
Product Depth | 19 1/8 Inches |
Product Height | 10 5/16 Inches |
Product Width | 30 Inches |
Dimensions | |
---|---|
Duct Size: | 6 in. round |
Weight: | 70 lbs. |
Depth: | 19 1/8 in. |
Height: | 10 5/16 |
Width: | 30 in. |
Features | |
Charcoal Filter: | Yes |
Convertible to Re-Circulating Installs: | Yes |
Duct Type: | Round |
Fan Speeds: | 3 |
Heavy Duty Grease Filters: | Yes |
Type: | Canopy |
Venting Style: | Vent |
Washable Filters: | Yes |
Lighting: | 2 Halogen |
Controls | |
Control Type: | Infinite Slide |
Capacity | |
Maximum Exhaust Capacity: | 600 Cubic feet per minute |
Electrical | |
Details: | 15 Ampere, 120 Volts, 60 Hertz (1/second), USE COPPER WIRE ONLY. GROUNDED CIRCUIT IS REQUIRED. A TIME-DELAY FUSE OR CIRCUIT BREAKER AND SEPARATE CIRCUIT IS RECOMMENDED. |
