Dimensions | |
---|---|
Class Width | 30" |
Width | 29.87 inch(es) / 75.88 cm |
Height | 3.87 inch(es) / 9.84 cm |
Depth | 21.25 inch(es) / 53.98 cm |
Additional Dimensions | Required Cutout Dimension (W x D): 28 3/8" x 19 5/16" |
Weight | 31.97 lb(s) / 14.5 kg |
Manufacturer's Warranty: 1 year
EAN: 8690842145865
General | |
Model | CTG30500SS |
Size | 30" |
Color | Stainless Steel |
Heating Technology | Gas |
Stainless Steel Frame | Yes |
Control Type | Front Knob Control |
Gas Burner Features | |
Sealed Burner | Yes |
Reignition Controlled Burners | Yes |
Gas Safety Device | Yes |
Cast Iron Continuous Grates | Yes |
Accessory | |
Griddle Pan | Yes |
Size and Power | |
Front Left | 4,500 BTU |
Front Right | 9,000 BTU |
Rear Left | 9,000 BTU |
Rear Right | 4,500 BTU |
Center | 18,000 BTU |
Dimensions / Weight | |
Required Cutout Dimension (H x W x D) | 28 3/8" x 19 5/16" |
Overall Height | 3 7/8" |
Overall Width | 29 7/8" |
Overall Depth | 21 1/4" |
Weight | 31.96 lbs |
Power / Ratings | |
KW / Amps Rating at 240 V, 60 Hz | 110 120 V, 60 Hz |
Supply Cord | Yes |
General | |
---|---|
Manufacturer Color | Stainless steel |
Color | Stainless Steel |
Type | Built-In |
Cooktop | |
Surface Features | • Stainless steel frame • Cast iron continuous grates |
Fuel Type | Natural Gas |
Burners | Sealed |
Burners/Elements | 5 |
Power Output | • Front left: 5,000 BTU • Front right: 10,000 BTU • Rear left: 10,000 BTU • Rear right: 5,000 BTU • Center: 20,000 BTU |
Features | |
Wi-Fi | No |
Clock | No |
Control Lock | No |
Digital Display | No |
Downdraft Ventilation | No |
Additional Information | • Front knob control with LED illumination • Reignition controlled burners • Gas safety device |
Accessories | |
Optional | Griddle pan |
Electrical Information | |
Information | • 110 - 120 V • 60 Hz |
Warranty | |
Warranty | • Limited 1 year parts and labor • Limiter 5 years parts only |
