- Burners range from 5,000 BTU to 12,000 BTU and are easy to clean.
- Heavy-duty UltraSoft grates are porcelain coated and featured on all sealed burner models.
"
"
Manufacturer's Warranty: 1 year
Color | Stainless Steel |
Power Type | Gas |
Exclusive Slimline 18" Depth Design | Yes |
Combo With Undercounter Wall Oven | Yes |
Cooktop Configuration | |
Removable Knobs | Yes |
Spill Control Cooktop | Yes |
UltraSoft Cast Iron Grates & Burner Caps | Yes |
Porcelain Coated Round Steel Grates | Yes |
Electronic Ignition | Yes |
Linear Flow Burner Valves | Yes |
9,100 BTU Power Burners | 2 |
12,000 BTU Power Burners | 1 |
5,000 BTU Low Simmer | 1 |
Black Porcelain Drip Pans | Yes |
Exterior Dimensions | |
Exterior Width | 36" |
Exterior Depth | 18" |
Exterior Height | 3-1/2" |
Cut-Out Dimensions | |
Cut-out Under-counter Clearance | 5" |
Cut-Out Width (Max.) | 34-3/8" |
Cut-Out Width (Min.) | 34-1/4" |
Cut-out Depth (Max.) | 16-3/4" |
Cut-Out Depth (Min.) | 16-5/8" |
Gas Inlet Location | Right Rear |
120V / 60HZ / 15 Amp Power Source Required | Yes |
LP Conversion Kit Included | Yes |
Shipping Weight (Approx) | 39 lbs |
UPC | 0-57112-09217-1 |
Model | FGC36S5EC |
Size | 36" |
Product Type | Gas |
Dimensions | |
---|---|
Height: | 3 1/2" |
Exterior Width: | 36 |
Depth: | 18" |
Cutout Width: | 34 1/4 inches |
Cutout Depth: | 16 5/8 inches |
Space Required Below Cooktop: | 5 inches |
Weight: | 39 lbs. |
Cut-out Undercounter Clearance: | 5 inches |
Cut-out Width (Min.): | 34 1/4 inches |
Cut-out Width (Max.): | 34 3/8 inches |
Cut-out Depth (Min.): | 16 5/8 inches |
Cut-out Depth (Max.): | 16 3/4 inches |
Width: | 36 inches |
Height: | 3 1/2 inches |
Depth: | 18 inches |
Nominal Product Size: | 36 inches |
Approx. Shipping Weight: | 39 lbs. |
Cooktop Features | |
Cooktop Type: | Stainless Steel Spill-Control Cooktop |
Linear Flow Gas Valves: | Front-Mounted |
Control Knob Type: | Removable |
Grate and Burner Type: | UltraSoftâ„¢ Design Cast Iron |
Elements | |
12,000 BTU Sealed Power Burner: | 1 |
5,000 BTU Sealed Burner with 500 BTU Low Simmer: | 1 |
9,100 BTU Sealed Burners: | 2 |
Installation Options | |
Above Undercounter Wall Oven: | Yes |
