ADA Compliant
ADA (Americans with Disabilities Act) compliant appliances from GE Appliances can help to make your home accessible to people with disabilities.
Manufacturer's Warranty: 1 year
UPC: 084691822240
EAN: 0084691822240
FILTER | |
App Filter - Cabinet Width | Cooking 36 in. |
App Filter - Cooktop Type | Radiant Smoothtop |
App Filter - Fuel Type | Electric |
App Filter - Control Type | Rotary knobs |
APPEARANCE | |
Frame Color / Material | Stainless Steel |
Color Appearance | Stainless Steel |
Control Knobs | Stainless Steel Appearance |
POWER / RATINGS | |
Recommended Circuit Breaker (Amps) at 240V | 40 |
Max. Connected Load (kW) at 240V | 9.0 |
Max. Current Draw (Amps) at 240V | 37.5 |
Max. Connected Load (kW) at 208V | 7.1 |
Electrical Requirements | 208/240V ; 60Hz ; 40A |
Recommended Circuit Breaker (Amps) at 208V | 40 |
Max. Current Draw (Amps) at 208V | 34.3 |
WARRANTY | |
Parts Warranty | Limited 1-year entire appliance |
Warranty Notes | See written warranty for full details |
Labor Warranty | Limited 1-year entire appliance |
WEIGHTS & DIMENSIONS | |
Cooktop Size | 36 in |
Overall Height | 3.375 in |
Cutout Depth (in) | 19 1/8 in |
Cabinet Width | 36 in |
Approximate Shipping Weight | 53 lb |
Overall Width | 36.125 in |
Net Weight | 46 lb |
Cutout Width (in) | 33.875 |
Overall Depth | 20.375 in |
FEATURES | |
Dishwasher Safe Knobs | Yes |
Cooktop Burner Type | 5 Ribbon Smoothtop |
Melt Setting | Yes |
Fuel Type | Electric |
Power Boil Burner | Yes |
Element - Left Front | 7" 1500W |
Indicator Lights | 5 Hot Surface Red Surface Element "ON" |
Dual Ring Burners | Yes |
Element - Right Front | 8" 2500W Power Boil |
Control Location | Front Center |
Cooktop Type | Radiant Smoothtop |
Cooktop Surface | Black Ceramic Glass with Stainless Steel Trim |
Cooktop Control Features | Fifth Element Warming Zone |
Element - Left Rear | 6" 120W Warming Zone |
Control Type | Knob (Infinite switch) |
Element - Center | 12"/9" 2700W dual |
Element - Right Rear | 6" 1200W (Melt) |
Product Type | Cooktop |
Colour Appearance | Stainless Steel on Black |
Control Knobs | Stainless Steel Appearance |
Frame Colour / Material | Stainless Steel |
ADA Compliant | Yes |
Control Location | Front Center |
Control Type | Knob (Infinite Switch) |
Cooktop Burners | 5 Burners |
Dishwasher Safe Knobs | Yes |
Element - Center | 9"/12" 2700W Power Boil |
Element - Left Front | 7" 1500W |
Element - Left Rear | 6" 1200W |
Element - Right Front | 8" 2500W Power Boil |
Element - Right Rear | 6" 1200W |
Element Type | 5 Ribbon |
Fuel Type | Electric |
Hot Surface | 5 |
Melt Setting | Yes |
Amp Rating at 208V | 34.3 |
Amp Rating at 240V | 37.5 |
KW Rating at 208V | 7.1 |
KW Rating at 240V | 9 |
Full 1 Year - Entire Appliance; In Home; Parts & Labor | Yes |
Approximate Shipping Weight (lbs.) | 53 |
Cooktop Width (in.) | 36 |
Cutout Dimensions (w x d) (in.) | 33-7/8 x 19-1/8 |
Net Weight (lbs) | 46 |
Overall Depth (in.) | 20-7/8 |
Overall Height (in.) | 3-3/8 |
Overall Width (in.) | 36 |
