Modular Cooktop Options — Allows the cooktop to be customized to suit individual cooking styles and tastes. Modules sold separately
Two-Burner Gas Module — Offers a range of temperature settings for cooking versatility
Downdraft Exhaust — Powerful exhaust system effectively pulls smoke and steam out of the kitchen
Sealed Cooktop Burners — Adhere to cooktop to help contain spills and make cleaning quick and easy
Continuous Grates — Provide a flat, sturdy surface allowing easy movement of pans between burners
Electronic Pilotless Ignition — Provides reliable burner ignition operation, eliminating the need for a standing pilot
- Accepts optional Select-Top modules (left bay)
- Shipped with unit (right bay), offers multiple temperature settings
- Powerful exhaust system effectively pulls smoke and steam out of the kitchen
- Keep spillover contained on cooktop, making cleaning quick and easy
Manufacturer's Warranty: 1 year
APPEARANCE | |
Control Panel Color | Black |
Color Appearance | Stainless Steel |
Cooktop Burner Grate Color | Black Matte |
FEATURES | |
Cooktop Burner Type | 2 Sealed |
Cooktop Surface | Deep Stainless Steel |
Ignition System | Electronic |
Accepts Modules | Left and Right Side |
Component Style | Downdraft Vent |
Burner - Right Front | 10,000 BTU |
Burner - Right Rear | 10,000 BTU |
Configuration | Dual Modular - Both sides accept optional modules |
Control Type | Infinite Heat Rotary |
Control Location | Upfront |
CFM/ Sones Rating | 390/ 6.5 (High Speed) |
Variable Speed Fan | 3 Speeds - Hi/Med/Low |
Cooktop Burner Grate Features | Dishwasher Safe |
Dishwasher Safe Knobs | Yes |
Fuel Type | Natural Gas (factory set) |
Gas Grill Module (sold separately) | JXGG90L (left side only) |
Griddle Module (sold separately) | JXGL90L (left side only, requires grill module (JXGG90L) to operate) |
LP Convertible | Yes, Kit Included |
Mix or Match Component Capability | Yes |
Optional Blower Mount Capabilities | Back or Straight Down |
Removable Grease Filter(s) | Yes |
Two Burner Gas Module (right side included) | JXGB90S (left side sold separately) |
Valves (Degree of Turn) | 270 |
POWER / RATINGS | |
Burner BTU Ratings (000's/BTU) - LP Gas | (1) 9.1 |
Burner BTU Ratings (000's/BTU) - Natural Gas | (1) 10.0 |
Griddle BTU Rating (000's/BTU) - LP Gas | (1) 9.1 |
Griddle BTU Rating (000's/BTU) - Natural Gas | (1) 10.0 |
Grill BTU Rating (000's/BTU) - LP Gas | (1) 9.1 |
Grill BTU Rating (000's/BTU) - Natural Gas | (1) 10.0 |
Volts/Hertz/Amps | 120v; 60Hz; 15A |
WARRANTY | |
Parts Warranty | Limited 1-year entire appliance |
Labor Warranty | Limited 1-year entire appliance |
Warranty Notes | See written warranty for full details |
WEIGHTS & DIMENSIONS | |
Approximate Shipping Weight | 74.0 |
Cabinet Width | 30.0 |
Net Weight | 64.0 |
Overall Depth | 21.75 |
Overall Height | 18.5 |
Overall Width | 30.0 |
Space Required Below Cooktop | 6.0 |
Dimensions | |
---|---|
Height: | 18 1/2" |
Exterior Width: | 30 |
Depth: | 21 3/4" |
Cutout Width: | 29 |
Cutout Depth: | 21 |
Space Required Below Cooktop: | 6 in |
Weight: | 64 lbs. |
FEATURES | |
Cooktop Surface: | Deep Stainless Steel |
Fuel Type: | Natural Gas (factory set) |
LP Convertible: | Yes, Kit Included |
Control Type: | Infinite Heat Rotary |
Left Bay: | Accepts All Optional Modules (sold separately) |
Right Bay: | Two Burner Gas Module Only (included) |
Cooktop Burners: | 2 Sealed, 10,000 BTU |
Cooktop Grates: | Continuous Black Matte |
Accepts Modules: | Left and Right Side |
Component Style: | Downdraft Vent |
Configuration: | Modular |
Gas Grill Module (sold separately): | JXGG90L (left side only) |
Griddle Module (sold separately): | JXGL90L (left side only, requires grill module (JXGG90L) to operate) |
Mix or Match Component Capability: | Yes |
Two Burner Gas Module (right side included): | JXGB90S (left side sold separately) |
Valves (Degree of Turn): | 270 |
Burner Flame Stability Chamber: | Yes |
Dishwasher Safe Grates: | Yes |
Dishwasher Safe Knobs: | Yes |
Electronic Pilotless Ignition: | Yes |
Removable Grease Filter(s): | Yes |
Variable Speed Fan: | 3 Speeds - Hi/Med/Low |
Downdraft Exhaust (CFM): | 400 |
Optional Blower Mount Capabilities: | Back or Straight Down |
Control Location: | Control Location |
Control Panel: | Black |
ADA Compliant: | Yes |
APPEARANCE | |
Color Appearance: | Stainless Steel |
Color Appearance Code: | SS |
DIMENSIONS | |
Cabinet Width: | 30 in |
Net Weight: | 64.00 lb |
Overall Depth: | 21 3/4 in |
Overall Height: | 18 1/2 in |
Overall Width: | 30 in |
Space Required Below Cooktop (In.): | 6 in. |
POWER / RATINGS | |
Burner BTU Ratings (000's/BTU) - LP Gas: | (1) 9.1 |
Burner BTU Ratings (000's/BTU) - Natural Gas: | (1) 10.0 |
Griddle BTU Rating (000's/BTU) - LP Gas: | (1) 9.1 |
Griddle BTU Rating (000's/BTU) - Natural Gas: | (1) 10.0 |
Grill BTU Rating (000's/BTU) - LP Gas: | (1) 9.1 |
Grill BTU Rating (000's/BTU) - Natural Gas: | (1) 10.0 |
Volts/Hertz/Amps: | 120V; 60Hz ; 15A |
