- Developed and refined by JennAir®, this downdraft ventilation system uses proximity ventilation that helps capture smoke, steam and odors at the cooking surface, whisking them down and out for a fresh, clean kitchen. It has been designed to provide optimal cooking performance, relying on a vertically mounted, 297 CFM Motor Class blower system.
- Light(s) positioned at the controls instantly show which element is still hot – even if the element has been turned off.
- Our crew relentlessly engages with JennAir® appliances day in, day out. Initiated in rigorous product, process and culinary training, this team answers to you—from sales to installation to ownership.
- We narrowed down our dedicated network to only the most experienced providers. Armed with extensive access to products and knowledge, their expertise is unmatched.
- Downdraft cooktops are manufactured to be used with ductwork, but this option enables conversion of the JX3™ downdraft cooktop to be used with a duct-free system. (Sold separately)
- Filter included with the duct-free kit that captures smoke, grease and moisture, and allows air to travel through the filter without a loss of air efficiency. The filter also has a replacement indicator.
- A single centrifugal blower motor combines with a perimetric design, allowing this ventilation system to operate at just 297 CFM Motor Class.
- Striking and inviting controls with LED lighting unleash performance at your touch.
- Sleek black glass with a beveled edge that seizes its surroundings. Lose yourself in the depths of infinite possibilities that dare you to explore your limits.
- Subtlety that dares to be ignored. Standing semi-flush at 3mm above the countertop, this precision edge is minimalism magnified.
- An electric element that features two element sizes at one position and has a maximum heat output of up to 3,000 watts for greater cooking flexibility.
- An electric element that features two element sizes at one position for greater cooking flexibility.
- Provides exceptional ventiliation performance built into an attractive design by capturing cooking vapors through a thin slot and speeding the air, all while maintaining quiet operation.
- Heating elements sealed underneath a ceramic glass cooking surface that offers up to 1,200 to 1,300 watts of power.
- Waiting expectantly beneath the stillness of obsidian black glass, electric elements are coiled to deliver heat upon command.
UPC: 883049592336
Details | |
Cooktop Surface Material | Ceramic Glass |
Description | |
Size (in.) | 30 |
Fuel Type | Electric Radiant |
Cooktop Type | Downdraft |
Certifications | |
ADA Compliant | Yes |
Energy Rating (kWh/year) | 258 |
Prop 65 | Standard |
UL | Yes |
Ventilation System | |
CFM Motor Class | 310 |
Number of Vent Speeds | 3 |
Design Type | |
Design Expression | Black Glass |
Cooktop Details | |
Left Front Element-Burner Type | Dual |
Right Front Element-Burner Power | 1200W |
Left Rear Element-Burner Size | 6in. |
Cooktop Element Style | Radiant |
Number of Cooking Element-Burners | 4 |
Left Rear Element-Burner Type | Hyper |
Right Rear Element-Burner Power | 3000W/1400W |
Right Rear Element-Burner Type | Dual-Stacked Burner |
Right Front Element-Burner Type | Single |
Left Front Element-Burner Size | 10in./6in. |
Right Rear Element-Burner Size | 9in./6in. |
Left Rear Element-Burner Power | 1,300W |
Cooktop Surface Color | Black |
Cooktop Selections | Convertible to Duct Free Ventilation,DownDraft |
Right Front Element-Burner Size | 6in. |
General | |
Accessory Relationships | Yes |
Controls | |
Control Location | Right Front |
Control Type | Electronic Touch |
Infinite Heat Controls | No |
Dimensions | |
Carton Depth(IN,inches) | 26.4375 |
Net Weight(LB,pounds) | 65 |
Carton Width(IN,inches) | 35.1250 |
Carton Height(IN,inches) | 23 13/16 |
Depth(IN,inches) | 22 1/16 |
Gross Weight(LB,pounds) | 78 |
Width(IN,inches) | 30.8750 |
Features | |
Installs Over Built-In Oven | No |
Power Boost | No |
Downdraft Vent | Yes |
Power Outage Compatible | No |
Automatic Pan Detection | No |
Digital Display | Yes |
Griddle | N/A |
Hot Surface Indicator Light | Yes |
Heating Element On Indicator Light | Yes |
LP Convertible | No |
Electrical | |
Volts | 220 |
Amps | 40 |
Power Cord Included | No |
