$2,925 | (10% off) | if you buy this item. |
$2,763 | (15% off) | if you buy 2 or 3 items. |
$2,600 | (20% off) | if you buy 4+ items. |
- Enjoy the robust heat necessary for high-powered cooking techniques, whether searing a steak, stir-frying vegetables or rapidly boiling water.
- Provides the optimal temperature for gently cooking delicate sauces and foods.
- Elegant brass burners effectively direct heat for desired cooking results and can be removed for easy cleaning.
- Keep the view from your kitchen open and free from ductwork with this optional kit that allows conversion to duct-free ventilation.
- With excellence in every detail, DuraFinish® Protection helps keep your cooktop s surface looking like new, resisting yellowing, staining and scratching.
- Developed and refined by JennAir®, this downdraft ventilation system uses proximity ventilation that helps capture smoke, steam and odors at the cooking surface, whisking them down and out for a fresh, clean kitchen. It has been designed to provide optimal cooking performance, relying on a vertically mounted, 297 CFM Motor Class blower system.
Manufacturer's Warranty: 2 years
UPC: 883049414447
EAN: 0883049414447
Certifications | |
Ada Compliant | Yes |
Prop65 | Standard |
Ul | Yes |
Controls | |
Control Location | Right Side |
Control Type | Knobs |
Infinite Heat Controls | Yes |
Cooktop Details | |
Cooktop Surface Color | Stainless |
Digital Display | No |
Griddle Included | N/A |
Heating Element On Indicator Light | No |
Hot Surface Indicator Light | No |
Ignition Type | Flame-Sensing™ Re-ignition |
Number of Open Bays | N/A |
Details | |
Cooktop Selections | Convertible to Duct Free Ventilation; Melt Cap |
Design Expression | Stainless Steel |
Fuel Type | Gas |
Installs Over Built-in Oven | No |
Lp Convertible | Yes - Kit Included |
Number of Vent Speeds | 3 |
Power Outage Compatible | Yes |
Dimensions | |
Product Height | 4.0 |
Cutout Depth | 19.938 |
Carton Height | 23.78 |
Gross Weight | 58 |
Carton Depth | 26.38 |
Carton Width | 35.12 |
Cutout Width | 28.625 |
Product Depth | 21.5 |
Net Weight | 46 |
Product Width | 30.0 |
Electrical | |
Power Cord Included | Yes |
Element/burner Details | |
Cooktop Element Style | Sealed Burner |
Cooktop Type | Downdraft |
Left Front Element-burner Power | 17,000 BTU |
Left Front Element-burner Type | Burner |
Left Rear Element-burner Power | 5,000 BTU |
Left Rear Element-burner Type | Burner |
Number of Cooking Element-burners | 4 |
Power Boost | No |
Right Front Element-burner Power | 10,000 BTU |
Right Front Element-burner Type | Burner |
Right Rear Element-burner Power | 15,000 BTU |
Right Rear Element-burner Type | Burner |
Exterior Details | |
Knob Color | Stainless Steel |
Knob Type | Metal |
Grate Details | |
Grate Details | Cast Iron Grates; Continuous; Dishwasher Safe; Matte Finish |
Number of Grates | 3 |
Ventilation Details | |
Cfm Motor Class | 310 |
Downdraft Vent | Yes |
Dimensions | |
---|---|
Depth | 21 1/2 |
Width | 30 |
Height | 4 |
Carton Depth | 26 7/16 |
Carton Height | 23 13/16 |
Carton Width | 35 1/8 |
Cutout Depth | 19 15/16 |
Cutout Height | 4 |
Cutout Width | 28 5/8 |
Gross Weight | 58 |
Maximum Height | 18 7/16 |
Net Weight | 46.0 |
Certifications | |
Prop 65 | Standard |
ADA Compliant | Yes |
UL | UL |
Configuration and Overview | |
Fuel Type | Gas |
Cooktop Type | Downdraft |
Size (IN,inches) | 30 |
Installs Over Built-In Oven | No |
LP Convertible | Yes - Kit Included |
Power Boost | No |
Controls | |
Control Type | Knobs |
Infinite Heat Controls | Yes |
Knob Color | Stainless Steel |
Knob Type | Metal |
Control Location | Right Side |
Appearance | |
Digital Display | No |
Cooktop Details | |
Downdraft Vent | Yes |
Hot Surface Indicator Light | No |
Heating Element On Indicator Light | No |
Number of Cooking Element-Burners | 4 |
Cooktop Surface Color | Stainless |
Cooktop Surface Material | Stainless Steel |
Number of Open Bays | NA |
Left Front Element-Burner Power | 17,000 BTU |
Left Rear Element-Burner Power | 5000 BTU |
Right Front Element-Burner Power | 10,000 BTU |
Left Front Element-Burner Type | Burner |
Right Rear Element-Burner Power | 15,000 BTU |
Left Rear Element-Burner Type | Burner |
Right Front Element-Burner Type | Burner |
Right Rear Element-Burner Type | Burner |
Grate Details | Cast Iron Grates,Continuous,Dishwasher Safe,Matte Finish |
Cooktop Element Style | Sealed Burner |
Ignition Type | Flame-Sensing™ Re-ignition |
Number of Grates | 3 |
Features | |
Griddle | NA |
Power Outage Compatible | Yes |
Selection | Brass Burners,Convertible to Duct Free Ventilation,JX3™ Downdraft Ventilation System with 3-Speed Fan,Melt Cap |
Electrical | |
Amps | 15 |
Hz | 60 |
Volts | 120 |
Power Cord Included | Yes |
Refinement | |
Style | Cooktops |
Ventilation System | |
CFM Motor Class | 310 |
Number of Speeds | 3 |
Design Type | |
Design Expression | Stainless Steel |
