Garantie du fabricant: 1 an
Base_Model | CGDS3065K |
Installation Type | Slide In |
Power Type | Dual Fuel |
Colour | White |
Sabbath Mode (Star-K® Certified) | Yes |
Exterior Finish | Painted |
Exterior Door Finish | Painted |
Control Panel | |
Interface | Membrane |
Knobs | Plastic Black Weighted |
Quick Bake | Yes |
Broil | Broil Variable |
Convection Bake | Yes |
Convection Broil | Yes |
Convection Roast | Yes |
Convection Conversion | Yes |
Preheat | Yes |
Quick Preheat | Yes |
Keep Warm | Yes |
Chicken Nugget Button | Yes |
Pizza Button | Yes |
Self-Clean | 2, 3, 4 Hours |
Delay Clean | Yes |
Add-a-Minute | Yes |
Timer Function | Yes |
Timer Lock-out | Yes |
Cooktop Configuration | |
Surface Type | Porcelain/Deep Drawn |
Grates | Continuous |
Grate Material | Cast Iron |
Grate Colour | Matte Black |
Front Right Burner (BTU) | 17000 BTU |
Front Left Burner (BTU) | 9500 BTU |
Rear Right Burner (BTU) | 5000 BTU |
Rear Left Burner (BTU) | 15000 BTU |
Oven Features | |
Capacity (Cu. Ft.) | 4.2 Cu. Ft. |
Bake Element (Watts) | 2500 |
Baking System | Dual Radiant |
Broil Element (Watts) | 8 pass 3400 watts |
Broiling System | Vari-Broil |
Convection Conversion | Effortless™ Convection |
Convection System | 3rd Element |
Hidden Bake Element | True Hidden Bake |
Rack Configuration | 3 with 1 Effortless™ 1 SpaceWise™ Half Rack, 1 Heavy Duty Handle Rack |
Light Type | Standard |
Light (No.) | 2 |
Cleaning System | Self-Clean |
Self-Cleaning Time | 2, 3, 4 Hours |
Window | Extra-Large Visualite™ |
Drawer Features | |
Drawer Functionality | Keep Warm |
Handle | New Gallery Metal - Black |
Oven Interior Dimensions | |
Interior Width | 24-1/8" |
Interior Depth | 18-1/32" |
Interior Height | 16-1/2" |
Exterior Dimensions | |
Exterior Width | 30" |
Exterior Depth | 28-5/16" |
Exterior Depth (to Center of Arc) | 28-5/16" |
Exterior Depth (with 90° Door Open) | 45-1/2'' |
Exterior Height | 35-5/8" - 36-5/8" |
Gas Supply Connection Location | Rear Bottom Right |
Power Supply Connection Location | Rear Bottom Left |
Connected Load (kW Rating) @ 240 / 208 Volts | 5.6 / 4.2 kW |
Voltage Rating | 240 / 208V / 60Hz |
Minimum Circuit Required (Amps) | 20 |
Product Weight | 240 lbs |
Shipping Weight (Approx.) | 260 lbs |
Cut-Out Dimensions | |
Cut-Out Width | 30-1/16" |
Cut-Out Depth | 21-3/4" - 22-1/8" |
Cut-Out Height | 35-7/8" - 36-5/8" |
Size | 30" |
UPC Code | 0-57112-10369-3 |
