Frigidaire

FFHS2322MW

GENERAL SPECIFICATIONS

• Annual Energy (kWH): 672
• Condenser Type: Dynamic
• Sound Package: Quiet Pack
• Water Inlet Location: Left Rear Bottom
• Shipping Weight (lbs): 285
• Product Weight (lbs): 260
• Power Type: Electric
• Size: 22 Cu. Ft.
• Installation Type: Free-Standing
• Collection: Frigidaire

CAPACITIES

• Capacity (Cu. Ft.): 22.1
• Fresh Food Capacity (Cu. Ft.): 14.2
• Freezer Capacity (Cu. Ft.): 7.9
• Total Shelf Area (Sq. Ft.): 19.1
• Fresh Food Shelf Area (Sq. Ft.): 13.8
• Freezer Shelf Area (Sq. Ft.): 5.3

ICE MAKER

• Ice Maker: Yes
• Ice Maker Type: Side-Mounted

CERTIFICATIONS & APPROVALS

• ENERGY STAR® Certified: No
• CSA Certified: Yes
• ADA Compliant: No

EXTERIOR SPECIFICATIONS

• Door Design: Tall
• Door Style: UltraSoft™
• Handle Design: Colour-Coordinated Plastic
• Door Hinge Covers: Hidden
• Cabinet Colour: Colour-Coordinated
• Toe Grille: Colour-Coordinated
• Front Rollers: Adjustable
• Rear Rollers: Yes
• Door Gasket: Colour-Coordinated
• Door Stops: Yes
• Door Closers: Yes

FREEZER SPECIFICATIONS

• Freezer Lighting: Standard
• Fixed Freezer Shelves: 1 Flip / 2 Wire
• Full-freezer Baskets: 1 Plastic
• Fixed Door Bins: 4 White

ELECTRICAL SPECIFICATIONS

• Voltage Rating: 120V 60Hz
• Amps @ 120 Volts: 8.5
• Minimum Circuit Required (Amps): 15A
• Connected Load (kW Rating) @ 120V: 1.02
• Power Supply Connection Location: Right Rear Bottom

CONTROLS

• Controls: Ready-Select® Electronic 1-9
• Control Location: Refrigerator Interior
• Controls Style & Colour: Colour-Coordinated Electronic Buttons
• Control Buttons: 5
• Water Filter Change Indicator Light: Yes

EXTERIOR DIMENSIONS

• Height: 69-7/8"
• Width: 33"
• Depth: 32"
• Case Height: 68-5/8"
• Height with Hinges and Covers: 69-7/8"
• Case Width: 32-7/8"
• Case Depth: 28-3/4"
• Depth with Doors (no Handles): 32"
• Depth with Doors and Handles: 34-1/2"
• Depth (with Door 90° Open): 48"
• Height to Top of Door: 70"
• Width between Door Edges: 33"

FRESH FOOD

• Energy Saver Plus: Yes
• Lighting Design: Standard
• Lighting Levels: Single-Level
• Water Filter: PureSource 3®
• Water Filter Location: Top Right Rear
• Cantilever Shelves: Yes
• Fixed Shelves: 3 SpillSafe®
• Upper Crisper: Clear
• Lower Crisper: Clear
• Humidity Controls: 1
• 1-Gallon Adjustable Door Bins: 2 White
• Fixed Door Bins: 2 Two-Liter White
• Dairy Compartment: Clear Dairy Door

DISPENSER

• Dispenser Type: Tall 2-paddle
• Crushed Ice: Yes
• Cube Ice: Yes
• Water: Yes
• Dispenser Lock: Yes
• Dispenser Light: Yes
