- A reversing fan circulates heat and air for evenly browned and baked foods
- Provides ideal airflow throughout the oven, ensuring optimal results on both racks
- Conceals the lower oven bake element to eliminate hard-to-reach areas that collect food and spills for easy cleaning
- Choose a 12-/9-/6- heating element to accommodate the size of your pan
- Accurate control ensures even heating and less temperature variation
- Self-clean allows you to spare yourself from the trouble and effort it takes to scrub the oven interior
Garantie du fabricant: 1 an
CAPACITY | |
Total Capacity (cubic feet) | 5.3 cu ft |
Unit Capacity | Super Large Oven |
FEATURES | |
Temperature Management System | TrueTemp System |
Configuration | Range with Storage Drawer |
Cooking Technology | Convection |
Cooktop Burner Type | Smoothtop Radiant |
Cooktop Surface | Patterned True White Glass Ceramic One-Piece Upswept |
Control Location | Backsplash |
Control Type | Glass Touch Controls QuickSet VI DigiTemp Temperature Display |
6" Heating Element(s) | 3 Ribbon (1,500W) |
6"/9"/12" Tri-Ring Element | 1 Ribbon (3,000W) |
8" Heating Element (s) | 1 Ribbon (2,000 watt) |
Cooking System | True European Convection Precise Air Convection System |
Cleaning Time | Variable with Delay Clean Option |
Self-Clean Oven Door Lock | Automatic |
Heating Element "ON" Indicator Light | Yes |
Hot Surface Indicator Lights | 5, Cooktop |
Interior Oven Light | Yes |
Oven Cleaning Type | Self-Clean |
Oven Control Features | Auto Recipe Conversion Convection Conversion Proof Mode Warm Mode Oven Meat Probe Delay Bake Option (Time Bake) C° or F° Programmable Audible Preheat Signal Auto Oven Shut-Off with Override Auto Self Clean Electronic Clock & Kitchen Timer Oven Function Icons Self-Cleaning Cycling Light Self-Clean Cool Down Time Display Oven "ON" Light Auto Certified Sabbath Mode Control Lock Capability Delay Clean Option Digipad Numeric Entry Variable Broil |
Oven Cooking Modes | Convection Bake Multi/Single Rack Convection Roast |
Oven Features | Dual Element Bake 6-Pass Power Bake Element |
Oven Rack Features | 3 Heavy-Duty Self-Clean Oven Racks |
Precise Digital Control System | Yes |
Preheated Oven Light | Display |
Storage Drawer Features | Removable Full-Width |
Style | Smoothtop |
Oven Interior | Hidden Bake |
APPEARANCE | |
Color Appearance | True White |
Handle | High-Gloss Color-Matched Sculptured |
Oven Door Features | Big ClearView Oven Window White Frameless Glass Door Frameless Lift-off Oven Door |
Textured Steel Side Panels | Yes |
WEIGHTS & DIMENSIONS | |
Approximate Shipping Weight | 206 lb |
Cabinet Width | 30 in |
Net Weight | 185 lb |
Oven Interior Dimensions (W x H x D) (in.) | 24-1/8 x 19-1/2 x 19-3/8 |
Overall Height | 46 1/2 in |
Overall Width | 29 7/8 in |
Overall Depth | 27 3/8 in |
Depth with Door Open | 47 5/8 in |
Depth Without Handle | 25 3/8 in |
POWER / RATINGS | |
Amp Rating at 208V | 40 |
Amp Rating at 240V | 40 |
KW Rating at 208V | 10.1 |
KW Rating at 240V | 13.4 |
ACCESSORIES | |
Cooktop Cleaning | Cream Sponge Included |
WARRANTY | |
Parts Warranty | Limited 1-year entire appliance Limited 5-year glass cooktop/radiant surface units |
Labor Warranty | Limited 1-year entire appliance |
Warranty Notes | For models produced on or after January 1, 2006 See written warranty for full details |
