- Conveniently cleans the oven cavity without the need for scrubbing
- Provides an impressively large oven interior for cooking more dishes and large meals at one time
- Delivers even heat distribution and maximum oven control
- Features an easy to use design that allows you to set precise cooking temperatures
- Provides consistent and even heat on the cooktop with a plug-in element that is removable for easy cleaning
- An extra large clear window makes monitoring the progress of food easy
Garantie du fabricant: 1 an
CAPACITY | |
Total Capacity (cubic feet) | 5.3 cu ft |
Unit Capacity | Super Large Oven |
FEATURES | |
Clean-Well Cooktop System | Yes |
Temperature Management System | TrueTemp System |
Configuration | Range with Storage Drawer |
Cooking Technology | Traditional |
Cooktop Burner Type | Coil |
Cooktop Surface | One-Piece Upswept Porcelain-Enamel |
Control Location | Backsplash |
Control Type | Touchpads QuickSet V DigiTemp Temperature Display |
6" Heating Element(s) | 2 Plug-In (1,500W) |
8" Heating Element (s) | 2 Plug-In (2,600W) |
Removable One-Piece Drip Bowls | Self-Clean |
Cleaning Time | Variable with Delay Clean Option |
Dishwasher Safe Knobs | Yes |
Heating Element "ON" Indicator Light | Yes |
Infinite Heat Controls | Yes |
Interior Oven Light | Yes |
Lift-Up Cooktop With Support Rods | Yes |
Oven Cleaning Type | Self-Clean |
Oven Control Features | Delay Bake Option (Time Bake) Delay Bake Option With Cook & Hold C° or F° Programmable Audible Preheat Signal Auto Oven Shut-Off with Override Auto Self Clean Electronic Clock & Kitchen Timer Start Pad Self-Cleaning Cycling Light Self-Clean Cool Down Time Display Oven "ON" Light Certified Sabbath Mode Control Lock Capability Delay Clean Option Digipad Numeric Entry Variable Broil |
Oven Features | Dual Element Bake 6-Pass Power Bake Element |
Oven Rack Features | 2 Heavy-Duty Self-Clean Oven Racks |
Preheated Oven Light | Yes |
Storage Drawer Features | Removable Full-Width |
Style | Coil |
APPEARANCE | |
Color Appearance | Black on Black |
Handle | Color-Matched High-Gloss |
Oven Door Features | Big ClearView Oven Window Black Frameless Glass Door Frameless Lift-off Oven Door |
Textured Steel Side Panels | Yes |
WEIGHTS & DIMENSIONS | |
Approximate Shipping Weight | 186 lb |
Cabinet Width | 30 in |
Net Weight | 166 lb |
Oven Interior Dimensions (W x H x D) (in.) | 24-1/8 x 19-1/2 x 19-3/8 |
Overall Height | 46 1/2 in |
Overall Width | 29 7/8 in |
Overall Depth | 27 3/4 in |
Depth with Door Open | 47 5/8 in |
Depth Without Handle | 25 3/8 in |
POWER / RATINGS | |
Amp Rating at 208V | 40 |
Amp Rating at 240V | 40 |
KW Rating at 208V | 8.8 |
KW Rating at 240V | 11.7 |
WARRANTY | |
Parts Warranty | Limited 1-year entire appliance Limited 5-year glass cooktop/radiant surface units |
Labor Warranty | Limited 1-year entire appliance |
Warranty Notes | For models produced on or after January 1, 2006 See written warranty for full details |
