- Self-clean allows you to spare yourself from the trouble and effort it takes to scrub the oven interior
- Remarkably large oven interior is ideal for holidays, dinner parties and everyday family cooking
- Conceals the lower oven bake element to eliminate hard-to-reach areas that collect food and spills for easy cleaning
- Tough, double-coated racks can stay in the oven during the self-clean cycle to eliminate hand cleaning
- Lower oven with heating up to 450° offers additional cooking space when you need it most
- Choose a 12"/9"/6" heating element to accommodate the size of your pan
Garantie du fabricant: 1 an
CAPACITY | |
Capacity (Cu. Ft.) | 5.3 Upper / 1.2 Lower |
Total Capacity (cubic feet) | 6.5 cu ft |
FEATURES | |
Temperature Management System | TrueTemp™ System |
Warming Drawer Features | 140-220 Degrees F Temperature Settings |
Configuration | Double Oven Range |
Cooking Technology | Traditional |
Cooktop Burner Type | Smoothtop Radiant |
Cooktop Surface | Patterned True White Glass Ceramic One-Piece Upswept |
Control Location | Backsplash |
Control Type | Touchpads QuickSet IV DigiTemp Temperature Display |
6" Heating Element(s) | 1 Ribbon (1,500 watt) |
6"/9"/12" Tri-Ring Element | 1 Ribbon (1,050/1,950/3,000W) |
7" Heating Element(s) | 2 Ribbon (1,800W) |
Bridge Element | 1 (800W) |
Warming Zone | 1-6" Ribbon (120W) |
Cleaning Time | Variable with Delay Clean Option |
Self-Clean Oven Door Lock | Automatic |
Dishwasher Safe Knobs | Yes |
Heating Element "ON" Indicator Light | Yes |
Hot Surface Indicator Lights | 1, Cooktop |
Infinite Heat Controls | Yes |
Interior Oven Light | Yes |
Lower Oven Features | Bake knob control; infinite heat settings |
Oven Cleaning Type | Self-Clean |
Oven Control Features | Delay Bake Option (Time Bake) C° or F° Programmable Audible Preheat Signal Auto Oven Shut-Off with Override Auto Self Clean Electronic Clock & Kitchen Timer Start Pad Self-Cleaning Cycling Light Self-Clean Cool Down Time Display Oven "ON" Light Certified Sabbath Mode Delay Clean Option Variable Broil Mis-Wire Detection |
Oven Features | Dual Element Bake 6-Pass Power Bake Element |
Oven Rack Features | 2 Heavy-Duty Self-Clean Oven Racks |
Preheated Oven Light | Display |
Oven Interior | Hidden Bake |
APPEARANCE | |
Color Appearance | True White |
Handle | Color-Matched Sculptured |
Oven Door Features | Big Hearth Oven Window White Frameless Glass Door Frameless Lift-off Oven Door |
Textured Steel Side Panels | Yes |
WEIGHTS & DIMENSIONS | |
Approximate Shipping Weight | 236 lb |
Cabinet Width | 30 in |
Net Weight | 216 lb |
Oven Interior Dimensions (W x H x D) (in.) | 24-1/8 x 19-1/2 x 19-3/8 |
Overall Height | 46 7/8 in |
Overall Width | 29 7/8 in |
Overall Depth | 27 3/4 in |
Depth with Door Open | 47 5/8 in |
Depth Without Handle | 25 3/8 in |
POWER / RATINGS | |
Amp Rating at 208V | 40 |
Amp Rating at 240V | 40 |
KW Rating at 208V | 10.7 |
KW Rating at 240V | 14.2 |
ACCESSORIES | |
Cooktop Cleaning | Cream Sponge Included |
WARRANTY | |
Parts Warranty | Limited 1-year entire appliance |
Labor Warranty | Limited 1-year entire appliance |
Warranty Notes | For models produced on or after January 1, 2006 See written warranty for full details |
