- A reversing fan circulates heat and air for evenly browned and baked foods
- The reversing fan and third, 2500-watt element surrounding a fan provides even browning on every rack
- Optimal for larger cuts of meat, this setting rotates the heat around all sides, sealing in the juices, producing rotisserie results at up to 25% faster than a conventional oven
- Self-clean allows you to spare yourself from the trouble and effort it takes to scrub the oven interior
- Choose a 12"/9"/6" heating element to accommodate the size of your pan
- Combines three cooktop elements into one large cooking area, ideal for griddles and gourmet pans
Garantie du fabricant: 1 an
CAPACITY | |
Unit Capacity | Super Large Oven |
FEATURES | |
Oven Cleaning Type | Self-Clean |
Cleaning Time | Variable |
Cooktop Burner Type | Smoothtop 5 Ribbon |
Cooktop Surface | Patterned True White Glass Ceramic |
Self-Clean Oven Door Lock | Automatic |
Style | Smoothtop |
6" Heating Element(s) | 1 Ribbon (1,200W) |
6"/9"/12" Tri-Ring Element | 1 Ribbon (1,050/1,950/3,000W) |
7" Heating Element(s) | 2 Ribbon (1,800W) |
Bridge Element | 1 (800W) |
Warming Zone | 1 Ribbon (120W) |
Control Location | Upfront |
Control Type | Glass Touch Controls EasySet III SmartSet Digital Temperature Display |
Cooking Technology | Traditional |
Dishwasher Safe Knobs | Yes |
Infinite Heat Controls | Yes |
Oven Control Features | Auto Recipe™ Conversion Proof Mode Warm Mode Delay Bake Option With Cook & Hold C° or F° Programmable Audible Preheat Signal Auto Oven Shut-Off with Override Electronic Clock & Kitchen Timer Start Pad Light Self Clean Mode Automatic Meat Thermometer Certified Sabbath Mode Control Lock Capability |
Oven Cooking Modes | Convection Bake Multi/Single Rack Convection Roast |
Cooking System | Precise Air™ Convection System |
Heating Element "ON" Indicator Light | Yes |
Hot Surface Indicator Lights | 4 |
Interior Oven Light | Yes |
Oven Features | 6-Pass Bake Element 6-Pass Broil Element |
Oven Rack Features | 3 Heavy-Duty Self-Clean Oven Racks |
Oven Interior | Hidden Bake |
CLAIMS & CERTIFICATIONS | |
APPEARANCE | |
Color Appearance | True White |
Handle | High-Gloss Color-Matched Sculptured |
Oven Door Features | Big ClearView™ Oven Window Frameless Lift-off Oven Door |
WEIGHTS & DIMENSIONS | |
Approximate Shipping Weight | 185 lb |
Net Weight | 165 lb |
Oven Interior Dimensions (W x H x D) (in.) | 24 x 17-1/2 x 18-1/4 |
Overall Height | 27 in |
Overall Width | 31 1/4 in |
Cabinet Width | 30 in |
Overall Depth | 26 1/2 in |
Depth with Door Open | 45 1/4 in |
Depth Without Handle | 23 13/16 in |
POWER / RATINGS | |
Amp Rating at 208V | 40 |
Amp Rating at 240V | 40 |
KW Rating at 208V | 8.7 |
KW Rating at 240V | 11.6 |
ACCESSORIES | |
Optional Backguard | JXS37WW (White) |
Optional Maintop Filler | JXS64WW (White) |
WARRANTY | |
Parts Warranty | Limited 1-year entire appliance Limited 5-year glass cooktop/radiant surface units |
Labor Warranty | Limited 1-year entire appliance |
Warranty Notes | For models produced on or after January 1, 2006 See written warranty for full details |
