Garantie du fabricant: 1 an
CAPACITY | |
Total Capacity (cubic feet) | 4.3 cu ft |
Unit Capacity | Super Large Oven |
FEATURES | |
Cooktop Burner Type | 4 Ribbon |
Control Location | Front |
Style | Built-In |
Infinite Heat Controls | Yes |
Cooking Technology | Trivection® |
Oven Cooking Modes | Convection Bake Multi/Single Rack Convection Roast Speed Bake Speed Broil |
Dishwasher Safe Knobs | Yes |
Storage Drawer Features | Removable Full-Width |
Oven Cleaning Type | Self-Clean |
Automatic Self-Clean Oven Door Lock | Yes |
Configuration | Range with Storage Drawer |
6" Heating Element (s) | 2 Ribbon (1500 watt) |
Oven Features | Optional Closed Door Broiling |
Oven Rack Features | 3 Heavy-Duty Oven Racks |
Hot Surface Indicator Lights | 4 |
Heating Element "ON" Indicator Light | Yes |
Leveling System | 4 Leveling Legs |
Interior Oven Light | Halogen (2) |
Temperature Management System | TrueTemp System |
Oven Control Features | Auto Recipe Conversion Proof Mode Warm Mode Defrost Mode Delay Bake Option With Cook & Hold Audible Preheat Signal Auto Oven Shut-Off with Override Auto Self Clean Electronic Clock & Kitchen Timer Oven Light Pad Start Pad Light Self Clean Mode Certified Sabbath Mode Control Lock Capability Cooking Complete Reminder Temperature Display |
6"/9" Dual Heating Element | 1 Ribbon (2500 watt) |
8" Heating Element (s) | 1 Ribbon (2000 watt) |
Cooking System | Precise Air Convection System |
Cooktop Surface | Grey Patterned on Black Glass Ceramic |
Sound Volume Control | Yes |
Control Type | Chef's Guide Glass Touch Controls EasySet III Digital Temperature Display |
APPEARANCE | |
Handle | Stainless Steel Sculptured |
Color Appearance | Stainless Steel |
Control Knobs | Heavy-duty die-cast |
Oven Door Features | Big ClearView Oven Window |
WEIGHTS & DIMENSIONS | |
Approximate Shipping Weight | 249 lb |
Depth with Door Open (in.) | 45 1/4 |
Cabinet Width | 30 in |
Cooktop Width | 31 1/4 in |
Net Weight (lbs.) | 228 lb |
Overall Height | 36 1/4 in |
Cabinet Opening | 30 in |
Overall Width | 31 1/4 in |
Overall Depth | 27 1/2 in |
Cavity (W x H x D) | 24 x 17-1/2 x 17-1/2 |
POWER / RATINGS | |
Amp Rating at 208V | 40 |
Bake Wattage | Dual 2500/900W |
Amp Rating at 240V | 40 |
Convection Wattage | 2500W |
KW Rating at 240V | 12.8 |
Broiler Wattage | 2500W |
KW Rating at 208V | 9.6 |
ACCESSORIES | |
Trivection® Cookbook | Included |
Optional Lower Trim Kit | JXS56BB (Black) |
Optional Body Sides | JXS77BB (Black) |
Optional Backguard | JXS37BB (Black) |
Cooktop Cleaning | Cream Sponge Included |
WARRANTY | |
Warranty Notes | For models produced on or after January 1, 2006 See written warranty for full details |
Labor Warranty | Limited 1-year entire appliance |
Parts Warranty | Limited 1-year entire appliance Limited 5-year glass cooktop/radiant surface units/magnetron tube |
Auto Recipeâ„¢ Conversion:: | Yes |
Cooking Technology:: | Trivection |
Element Type:: | 4 Ribbon |
Precise Airâ„¢ Convection System:: | Yes |
Proof Mode:: | Yes |
Style:: | Built-In |
Warm Mode:: | Yes |
Convection Bake:: | Multi/Single Rack Bake |
Convection Roast:: | Yes |
Defrost Mode:: | Yes |
TrueTempâ„¢ System:: | Yes |
Speed Bake:: | Yes |
Speed Broil:: | Yes |
Automatic Self-Clean Oven Door Lock:: | Yes |
Cooking Complete Reminder:: | Yes |
Electronic Oven Control:: | EasySet III |
Infinite Heat Controls:: | Yes |
Start Pad:: | Yes |
Touchpad Controls:: | Chef's Guide Glass Touch |
Oven Pad Light:: | Yes |
Heating Element : | Yes |
Interior Oven Light:: | Halogen (2) |
Sound Volume Control:: | Yes |
Dishwasher Safe Knobs:: | Yes |
Optional Closed Door Broiling:: | Yes |
Removable Full-Width Storage Drawer:: | Yes |
Storage Drawer:: | Yes |
Oven Door(s) with Window(s):: | Big ClearViewâ„¢ Window |
