- A reversing fan circulates heat and air for evenly browned and baked foods
- Convection fan system is only 1" deep to provide additional room for cookware
- Offers three specialized modes for different cooking needs: single-rack convection baking, multi-rack convection baking and convection roasting
- Interior heating element loops eight times to distribute heat quickly and evenly for optimal baking results
- Provides a more even coverage of the food on the broiler pan
- Electronic pads on the control panel are easy to operate with just a touch
Garantie du fabricant: 1 an
Configuration | Single Oven |
Cooking Technology | Convection |
Cooking System | Precise Air™ Convection System |
Oven Cleaning Type | Self-Clean |
Temperature Management System | TrueTemp™ System |
Cleaning Time | Variable with Delay Clean Option |
Control Type | SmartSet |
Oven Cooking Modes | Convection Bake Convection Roast Thermal Bake / Thermal Roast |
Self-Clean Oven Door Lock | Automatic |
Oven Features | 6-Pass Broil Element 8-Pass Bake Element Closed Door Broiling |
Oven Rack Features | 3 Heavy Duty Oven Racks 7 Embossed Rack Positions |
Interior Oven Light | 2 |
Oven Control Features | Auto Recipe™ Conversion Convection Conversion Delay Bake Option With Cook & Hold C° or F° Programmable Audible Preheat Signal Auto Oven Shut-Off with Override Electronic Clock & Kitchen Timer Oven Light Pad Start Pad Light Self Clean Mode Certified Sabbath Mode Control Lock Capability Digipad Numeric Entry Variable Broil Optional Clock Display Temperature Display |
Oven Interior | Hidden Bake |
CAPACITY | |
Total Capacity (cubic feet) | 4.4 cu ft |
APPEARANCE | |
Color Appearance | Bisque on Bisque |
Frameless Oven Door(s) | Color-Matched |
Oven Door Features | Big ClearView™ Oven Window |
Handle | Color-Matched Premium |
Installation | Under Cooktop Undercounter Flush Appearance |
claims & certifications | |
ADA Compliant | |
WEIGHTS & DIMENSIONS | |
Approximate Shipping Weight | 122 lb |
Net Weight | 105 lb |
Overall Height | 28 1/4 in |
Overall Width | 29 3/4 in |
Overall Depth | 23 1/2 in |
Cabinet Width | 30 in |
Cutout Dimensions (w x h x d) (in.) | 28 1/2 x 27 1/4 x 23 1/2 |
Oven Interior Dimensions (W x H x D) (in.) | 24 x 17-1/2 x 18-1/4 |
POWER / RATINGS | |
Amp Rating at 208V | 20 |
Amp Rating at 240V | 20 |
Bake Wattage | 2100W |
Broiler Wattage | 2400W |
Convection Wattage | 2500W |
KW Rating at 208V | 3.4 |
KW Rating at 240V | 4.5 |
WARRANTY | |
Parts Warranty | Limited 1-year entire appliance |
Labor Warranty | Limited 1-year entire appliance |
Warranty Notes | For models produced on or after January 1, 2006 See written warranty for full details |
