Garantie du fabricant: 1 an
CAPACITY | |
Heating - Reverse Cycle - BTUH | 13,400/13,200 |
CFM Indoor Fan Low | 330 |
Vent CFM | 70/65 |
CFM Indoor Fan High | 350 |
Cooling E.E.R. (BTUH / Watt) | 10.0/10.0 |
Dehumidification (pts./hr.) | 4.8 |
Sensible Heat Ratio at 265 Volts | 65% |
Cooling BTUH | 14700 Btu |
FEATURES | |
Auto Frost Control Monitor | Yes |
Fan Cycle Switch | Yes |
Heat - Cool | Yes |
Electronic Micro Computer Control | Yes |
Temperature Limiting | Electronic 7-Step |
Weather Protected Electrical Components | Yes |
Manual Vent Control | Hidden |
Heat Pump | Yes |
Central Desk Control Compatibility | Yes |
Rotary Compressor | Yes |
Upfront Filter | Yes |
Freeze Sentinel | Yes |
Louver Style | Adjustable |
Auto Power Recovery | Yes |
Solid State Thermostat Control | Yes |
Remote Control | Compatible |
APPEARANCE | |
Color Appearance | Pigeon Gray |
WEIGHTS & DIMENSIONS | |
Approximate Shipping Weight | 144 lb |
Net Weight (lbs.) | 129 lb |
Overall Height | 16 in |
Overall Width | 42 in |
Overall Depth | 13 3/4 in |
POWER / RATINGS | |
Cooling - Watts | 1470/1440 |
Cooling - Amperes; L.R. | 38.0 |
Power Factor | 95 |
Cooling - Amperes; F.L. - Cooling | 6.7/7.3 |
WARRANTY | |
Warranty Notes | For models produced on or after January 1, 2006 See written warranty for full details |
Labor Warranty | Limited 1-year entire appliance Limited 5-year sealed refrigerating system |
Parts Warranty | Limited 1-year entire appliance Limited 5-year sealed refrigerating system |
Dimensions | |
---|---|
Sleeve Width: | 1 |
Sleeve Height: | 1 |
Minimum Window Opening Width (in.): | 1 |
Maximum Window Opening Width (in.): | 1 |
Minimum Window Opening Height (in.): | 1 |
Depth to Louvers (in.): | 1 |
Interior Unit Height (Mini-split systems only): | 1 |
Interior Unit Width (Mini-split systems only): | 1 |
Interior Unit Depth (Mini-split systems only): | 1 |
Weight: | 150 lbs. |
Appearance | |
Chassis: | slide out |
Color: | pigeon gray |
Control Type: | knobs |
Performance | |
Cooling BTU: | 14600 |
Heating BTU: | 13400 |
Features | |
Heat: | heat pump |
Filter Type: | upfront |
Technical Details | |
Airflow: | 350 |
Cooling Amps: | 6.7 |
Cooling EER: | 10.0 |
Cooling Watts: | 1470 |
Dehumidification: | 4.8 |
Heating EER: | 10.0 |
Volts: | 220 |
