Garantie du fabricant: 1 an
CAPACITY | |
Total Capacity (cubic feet) | 1.4 cu ft |
FEATURES | |
Drive System | 2-point |
Control Location | Hidden |
Construction | Heavy Gauge Steel |
Compactor Features | Lock/Start Control w/Removable Key Side Release Bin Slide-Out Drawer |
Style | Built-In |
Ram Force (lb.) | 2300 lbs. |
Compression Ratio (Avg.) | 75% Reduction or 4:1 |
Motor Horsepower | 1/3 hp |
Cycle Time | Less than 30 seconds |
Leveling System | Leveling Legs with Rear Wheels |
APPEARANCE | |
Panel Capability | 3/4" Panel |
Color Appearance | Custom Panels Required |
WEIGHTS & DIMENSIONS | |
Height With Legs Retracted (In.) | 33-3/4 |
Approximate Shipping Weight | 144 lb |
Cabinet Width | 15 in |
Height w/Legs Extended (in.) | 35 |
Net Weight (lbs.) | 128 lb |
Cutout Dimensions (H x W x D in inches) | 34-1/4 x 15-1/8 x 24-3/4 |
Overall Height | 33 3/4 in |
Overall Width | 14 7/8 in |
Overall Depth | 23 in |
POWER / RATINGS | |
Volts/Hertz/Amps | 120V; 60Hz; 6.5A |
ACCESSORIES | |
Optional Accessories - Compactor Bags | WC60X5017 (2 Included) |
WARRANTY | |
Warranty Notes | For models produced on or after January 1, 2006 See written warranty for full details |
Labor Warranty | Limited 1-year entire appliance |
Parts Warranty | Limited 1-year entire appliance |
Dimensions | |
---|---|
Cutout Height: | 34 1/4 |
Cutout Width: | 15 1/8 |
Cutout Depth: | 24 3/4 |
Height with Legs Extended: | 35 |
Weight: | 150 lbs. |
Capacity: | 1 |
Features | |
Hidden Control Location: | Yes |
Less than 30 seconds Cycle Time: | Yes |
2-point Drive System: | Yes |
Lock/Start Control w/Removable Key: | Yes |
Side Release Bin: | Yes |
Slide-Out Drawer: | Yes |
Built-In: | Yes |
Heavy Steel Gauge Construction: | Yes |
Leveling Legs: | Yes |
Optional Accessories - Compactor Bags: | Yes |
Automatic Anti-Jam: | Yes |
Toe Pedal Drawer Opener: | Yes |
1-year Parts and Labor Warranty: | Yes |
Performance | |
4 to 1 Compression Ratio : | Yes |
1/3 hp Motor Horsepower: | Yes |
2300 lbs. Ram Force: | Yes |
Capacity | |
Capacity (cu. ft.): | 1.4 |
Electrical Requirements | |
Volts: | 120 |
Amps: | 6.5 |
