| Product Code |
CGMV174KF |
| Product Type |
Over-The-Range |
| Power Type |
Electric |
| Size |
1.7 Cu. Ft. |
| Installation Type |
Over-the-Range |
| UPC Code |
0-12505-56041-5 |
| Colour |
Stainless Steel |
|
| Depth |
16-3/16" |
| Depth (Including Rear Extrusion) |
16-3/16" |
| Height |
16-3/8" |
| Height (Including Lower Extrusion) |
16-3/8" |
| Width |
29-15/16" |
|
| Auto Cook Options |
8 Options - Frozen Breakfast, Scrambled Eggs, Hot Cereal, Chicken and Rice, Meatloaf, Roast Pork, Seafood Pasta, Vegetarian Medley |
| Auto Defrost (Keep Warm) |
Yes |
| Auto Defrost Options |
6 Options (Ground Meat, Steaks/Chops/Fish, Chicken Pieces, Roast, Casserole, Soup) |
| Cooking - Multiple Stages |
5 Stages |
| Snack Menu Options |
5 Options - Frozen MW Pizza, Frozen Sandwhich, Meal in a Cup, Hot Dogs, Soup |
|
| Depth (Including Rear Extrusion) |
16-3/16" |
| Height |
16-3/8" |
| Height (Including Lower Extrusion) |
16-3/8" |
| Width |
29-15/16" |
|
| Product Weight (lbs) |
55 |
|
| Audible Signal On/Off / Adjustable |
On / Off |
| Auto Start |
Yes |
| Child Lock |
Yes |
| Clock |
Yes |
| Language (En/Fr/Sp) |
Yes |
| User Preferences |
Yes |
| User Selectable Weight (lb/kg) |
Yes |
|
| Capacity (Cu. Ft.) |
1.7 |
|
| CDRH Approval |
Yes |
| UL/cUL Approval |
Yes - cUL |
|
| 30-Minute Warm Hold |
Yes |
| Baked Potato Button |
Yes |
| Chicken Nuggets Button |
Yes |
| Cooking - Multiple Stages |
No Pad (3-Stages) |
| Popcorn Button |
Yes |
| Reheat Button |
Yes |
| Sensor Cooking Options |
5 Options - Frozen Entrees, Ground Meat, Rice, Fish/Seafood, Chicken Breast |
| Snack Button |
Yes |
| Vegetable Cook Sensor |
Frozen and Fresh Veggies |
|
| Amps @ 120 Volts |
14.2 |
| Connected Load (kW Rating) @ 120V |
1.64 |
| Power Supply Connection Location |
Right Rear Top |
| Voltage Rating |
120V, 60Hz |
|
| Interior Light |
Yes |
| Microwave Interior Depth |
14-7/16" |
| Microwave Interior Height |
8-7/8" |
| Microwave Interior Width |
21" |
|
| Auto-start Heat Sensor |
Yes |
| Charcoal Filter |
2 |
| Vent Style |
Hidden |
| Lights |
2 |
| Cooktop Light Wattage |
20 |
| Ducted / Ductless Vent Installation |
Yes |
| Exhaust Fan Speeds |
2 speeds - 180/300 CFM |
| Grease Filter (Dishwasher Safe) |
2 |
| Heat Deflector |
Yes |
| Cooktop Light |
Incandescent |
|
| Cut-Out Depth (Min) |
12" |
| Cut-Out Depth (Max.) |
14" |
| Cut-Out Width |
30" |
| Cut-Out Height (Min) |
16-3/4" |
| Cut-Out Height (Max) |
17" |
|
| Add 30 Seconds |
With Start pad |
| Numeric Touch Pad |
Yes |
| Power Levels |
High / 1-9 |
| Quick Settings (Time) |
Yes 1 - 3 |
| Turntable On / Off |
Yes |
| Cooking - Multiple Stages |
No Pad (3-Stages) |
|
| Cut-Out Depth (Max.) |
14" |
| Cut-Out Depth (Min) |
12" |
| Cut-Out Height (Max) |
17" |
| Cut-Out Width |
30" |
|
| Exterior Finish |
Smudge-Proof Stainless Steel |
|
| Frequency (Mhz) |
2,450 |
| Interior Light Wattage |
20 |
| Microwave Turntable Diametre |
13" |
| Watts |
1,000 |
|
| 36" Filler Panel Kit (Stainless Steel) |
Optional, order item no. MWFILKTSS |
| Removable Metal Rack |
Included |
Colour: Stainless Steel
Capacity / Cavity Size (Cu. Ft.): 1.7 Cu. Ft.
Watts (IEC-705 Test Procedure): 1000 watts
Installation Type: OTR
Oven Interior Colour: White
Turntable (Diameter): 13"
Interior Light: Incandescent
Interior Light Wattage: 20
Control Panel Features
Controls: Side Controls
Electronic Controls Type: Membrane
Display Type: VFD
Display Colour: Green
Touch Pads Controls (# Pads): 28
Electronic Clock: Yes in User Pref
Timer: MM:SS
Start: Yes with 30 sec add feature
Stop / Cancel: Yes
Add 30 Sec: With Start pad
Turntable Off / On: Yes
Number pads 1 - 0: Yes
Power Levels: High / 1-9
Auto Mode Features
Auto Cook Options: 8 Options - Frozen Breakfast/Scrambled Eggs/Hot Cereal/Chicken and Rice/Meatloaf/Roast Pork/Seafood Pasta/Vegetarian Medley
Snack Menu Options: 5 Options - Frozen MW Pizza/Frozen Sandwhich/Meal in a Cup/Hot Dogs/Soup
Auto Defrost Options: 6 Options - Ground Meat/Steaks-Chops-Fish/Chicken Pieces/Roast Pork/Casserole/Soup
Keep Warm: Yes
Sensor Modes Features
Sensor Cook Options: 5 Options - Frozen Entrees/Ground Meat/Rice/Fish-Seafood/Chicken Breast
Popcorn Options: Yes
Snack: Yes
Chicken Nuggets: Yes
Baked Potatoes: Yes
Sensor Reheat: Yes
Veggie Options: Frozen and Fresh Veggies
User Preference - Custom Help Options: Yes
Clock: Yes
Child Lock: Yes
Auto Start (Delayed Cooking): Yes
Language (Eng./Fr./Sp.): Yes
Weight (Lbs./Kg.): Yes
Demo Mode: Yes
Audible Signal On / Off / Adjustable: On/Off
30-Minute Warm Hold: Yes
Vent (High): Yes
Vent (Low): Yes
Vent (Off): Yes
Ventilation/Light System
Hood Fan Speeds / CFM Rating: 2 speeds - 180/300
Vent (Hidden or Open): Hidden
Ducted / Ductless Vent Installation: Yes
Grease Filter (Dishwasher Safe): 2
Charcoal Filter: 2
Cooktop Light: Incandescent
Cooktop Light Wattage: 20 watts
Cooktop Light Bulbs (No.): 2
Heat Deflector: Yes
Auto-start Heat Sensor: Yes
Accessories
Removable Metal Rack: Included
36" Filler Panel Kit (Stainless Steel): MWFILKTSS - Optional
Oven Cavity Dimensions
Width: 21"
Depth: 14-7/16"
Height: 8-7/8"
Exterior Dimensions
Exterior Width: 29-15/16"
Exterior Depth: 16-15/16"
Exterior Height: 16-3/8"
Cut-Out Width: 30"
Cut-Out Depth (Max.): 14"
Cut-out Depth (Min.): 12"
Cut-out Height (Max.): 17"
Cut-out Height (Min.): 16-3/4"
UL/cUL Approval: Yes
CDRH Approval: Yes
Power Supply Connection Location: Right Top Rear
Voltage Rating Volts / Freq. / Amps: 120V / 60 Hz / 14.2 amps
Connected Load (kW Rating) @ 120 Volts: 1.64 kW
Amps @ 120V: 14.2
Watts @ 120 Volt Input: 1640 watts
Frequency (Mhz): 2450
Product Weight: 55.00 lbs
Shipping Weight: 63 lbs
UPC Code: 0-12505-56041-5
Size: 1.7 cu. ft.
