CMCELH
Replaced by MTR1303BL
Why Buy This at CAS?
In Home Delivery
Up to 2% cash-back* When paying by Visa® or Mastercard®
Custom Advanced Installation Services
Reserve & Pick Up
Interior Designer Discounts
Flexiti Financing as low as $28.62 for 18 months
Ratings & Reviews
CMCELH
When will I get this?
Description & Features
Specs
Manuals
Video
Reviews
Rebates
Warranty
Financing
Install
Delivery
Alta BQLA1 Series The sculpted lines of Alta bring an exciting, new choice to typical range hood shapes. Infrared controls, hybrid baffle filters and LED lighting lends a pro-style edge to your kitchen.
Features & Benefits
Features & Benefits
- The Captur system's advanced blower design features a forward positioned centric inlet to remove smoke and odor faster. Three-speed blower control exhausts at a strong 400 CFM Max high
- Smooth-flow blower wheel design and high flow filters ensure quiet, less than 0.5 sones operation at normal speed
- Bright, three-level LED modules - supported by a 3-year warranty - illuminate evenly and are tested in cooking environments to ensure long life without dimming. Color Temperature 3000 K
- Three-speed, whisper touch infrared control is a pleasure to use and admire. Delay off feature runs the blower for 10 minutes after cooking to clear the air
- Broan Heat Sentry detects excessive heat and adjusts the blower speed to prolong the life of the product and provide proper ventilation
- Dishwasher-safe, hybrid baffle filters provide ultra-efficient grease removal with superior air flow. The filter clean reminder ensures they will always maintain a high level of capture
- EZ1 brackets make it easy for single person installation in less than half the time of traditional methods
- ADA compliant, remote operation is possible using a standard UL approved wall switch. See additional information above
- Non-duct capable with use of charcoal filters, sold separately. Hidden louvers on top of hood exhaust away from cabinetry
- Optional HCR3 handheld remote enables control from anywhere in the kitchen
- EZ1 Installation System
- We watched countless installations as we set out to simplify and accellerate the process. The result is a two-bracket system that holds the hood for you while you make electrical and ducting connections. It's easy and fast - up to 50% less installation time.
- Superior Capture Over the Competition
- The Broan Captur exhaust ventilation system provides the fastest air flow management and filtration in its class for better performance, quieter operation and less energy use.
- Brilliant LED Lighting
- Energy-efficient LEDs provide bright, even lighting that will last many years without dimming. These LEDs are specially designed to withstand high heat cooking environments.
- Control. Just the Way You Want it.
- Three-speed, whisper touch infrared control is a pleasure to use and admire. Delay off feature runs the blower for 10 minutes after cooking to clear the air
- Functional Filtration for Your Sense of Style
- Pro-style, dishwasher-safe, hybrid baffle filters provide ultra-efficient grease removal with superior air flow.
- EZ1 Installation System
- We watched countless installations as we set out to simplify and accellerate the process. The result is a two-bracket system that holds the hood for you while you make electrical and ducting connections. It's easy and fast - up to 50% less installation time.
- Superior Capture Over the Competition
- The Broan Captur exhaust ventilation system provides the fastest air flow management and filtration in its class for better performance, quieter operation and less energy use.
The uncompromising choice
Air quality is a top concern for today’s families. The Broan series, with its superior capture efficiency, is the ideal solution. This model is sure to win over even the most demanding users with its innovative design, advanced technology, and unmatched performance.
SOPHISTICATED STYLE
- CapturTM exclusive system that provides faster smoke & odor removal
- 3-speed, whisper touch infrared control
- 3-level lighting built-in LED modules (2) that provide an even lighting over the cooktop
- Optional HCR3 handheld remote enables control from anywhere in the kitchen
- Two ultra efficiency hybrid baffle filters, easy to clean
- Filter clean reminder
- 10 minute delay off setting
- Automatic heat sensor function
- Performant dual blower
- HVI certified
- Quietest range hood offering a sound level of 0.3 sone at low speed
- Use charcoal filter HPF30 for a non-ducted installation
- EZ 1 brackets make it easy for single-person installation in less than half the time of traditional methods
- ADA compliant, remote operation is possible using a standard UL approved momentary wall switch. Requires ADA Wiring Kit.
Manufacturer's Warranty: 1 year
Canadian model: BQLA130BL
Canadian UPC: 026715249657
EAN: 0026715249657
| Color Finish | Black |
| CFM | 400 Max high - 150 Min normal |
| Sones | 6.0 Max high - 0.4 Min normal |
| Product Depth | 22" |
| Product Height | 5" |
| Product Width | 29-7/8" |
| Light Number Of Levels | 3 |
| Light Color Temp | 3000 K |
| Light Lumens | 450/module |
| Light Type | LED |
| Nightlight Or Nightlight Setting | No |
| Light Bulb Wattage | 4.5/module |
| Light Bulb Recommended Type | Integrated LED Module |
| Light Bulbs Included | Yes |
| Light Bulb Quantity | 2 LED Modules |
| Filter Quantity | 2 |
| Boost Mode | No |
| Heat Sentry® - Temperature Sensor | Yes |
| Filter Type | Hybrid Baffle |
| Motor Number Of Speeds | 3 |
| Built In Timer | No |
| Remote Operation Capable | No |
| ADA Compliance | Yes |
| Damper Included | Yes |
| Non-ducted Filter Included | No |
| Amperage | 1.4 |
| Rated Voltage | 120 |
| Wattage | 168 |
| Switch Control Type | Infrared |
| Non-Ducted Recirculation Capable | Convertible built-in |
| Warranty | 1 Year, 3 Year LED module |
| UL Listed | Yes |
| Duct Connector Size | 3-1/4" x 10" or 7" Round |
| Duct Direction | Horizontal/Vertical |
| Duct Shape | Rectangular or Round |
| Duct Diameter | 7" |
| Duct Height Rectangular | 3-1/4" |
| Duct Width Rectangular | 10" |
| HVI Certified | Yes |
| ENERGY STAR® certified product | No |
| Boost Mode | No |
| Category | Premium $$$$ |
| CFM (Airflow) | 400 |
| Color/Finish | Black |
| Control Type | 3-speed, whisper touch infrared control |
| Ducting Size | 3-1/4 in X 10 in (H-V) or 7 in Round |
| ENERGY STAR® Certified | No |
| Filter Type | Ultra Efficiency Hybrid Baffle Filters |
| Heat Sentry™ Automatic Heat Sensor | Yes |
| Lighting Intensity | 3 |
| Lighting Type | Two built-in LED modules |
| Non-Ducted Re-circulation Capable | Yes |
| Optionnal Control | No |
| Product Width (in) | 30 |
| Series | Alta |
| Sones | 0.3 |
| Ventilation Speeds | 3 |
| Warranty | 3 Years on LED modules 1 Year |
Spec Sheet BQLA1 (BQLA130BL-spec-sheet-bqla1-canada.pdf)
