Broan

BU224WH

• Broan® BU2 Series design – part of the Broan® BU2 Series, built to simple, reliable standards for everyday kitchen ventilation.

• Four-way convertible ventilation – installs as horizontal, vertical, round or non-ducted, giving flexibility for new builds or replacements in existing cabinetry.

• Convertible ducted or ductless operation – supports traditional ducted venting or non-ducted recirculation (with optional charcoal filter) to suit different kitchen layouts.

• 2-speed rocker control – streamlined rocker switch lets you quickly select low or high fan speed and operate the light.

• Two-speed blower – dual-speed fan lets you choose quieter operation for light cooking or higher power when frying or boiling.

• Up to 210 CFM ventilation performance – maximum blower capacity helps pull smoke, steam and cooking odours away from the cooktop for improved air quality.

• HVI certified performance – independently tested to HVI standards so airflow and sound ratings are verified for real-world use.

• Standard 160 CFM airflow rating – delivers effective everyday ventilation for smaller ranges and compact kitchens.

• 6.5 sones sound level (high) – standard-noise performance at top speed, balancing ventilation power with acceptable sound levels.

• 24" under-cabinet range hood – compact 24-inch width fits smaller ranges and tight spaces while providing full cooktop coverage.

• Low-profile 6" height – slim design tucks neatly under cabinets to maintain sightlines and maximize headroom over the cooktop.

• Standard 17.5" depth – projects far enough to capture rising smoke and steam from front and back burners.

• Contemporary styling – clean, simple lines in white finish coordinate easily with a wide range of kitchen styles and appliances.

• Durable steel construction – sturdy metal body is designed for long-term use and everyday cooking conditions.

• Aluminum mesh grease filter – standard-efficiency aluminum filter traps grease particles to help keep the hood interior and ductwork cleaner.

• Easy-to-clean filter – removable aluminum filter can be washed and reinstalled, reducing replacement costs and maintenance time.

• Non-ducted charcoal filter option – compatible with optional 41F charcoal filter for odour reduction when installed in recirculating (ductless) mode.

• Single 75 W incandescent light (bulb not included) – one A19 bulb socket provides bright, focused illumination over the cooking surface.

• One-level lighting – simple on/off lighting control for straightforward operation.

• Direct cooktop lighting – light is positioned to shine directly on the cooking area for better visibility while preparing meals.

• 120 V, 60 Hz operation – standard North American electrical requirements for easy integration into existing kitchen wiring.

• Approx. 2.5–2.6 A current draw – modest electrical load suitable for typical household circuits.

• 300 W maximum power rating – supports the blower motor and 75 W light while remaining energy-conscious for an economy hood.

• Minimum 18" clearance above cooktop – designed to install safely within common height ranges above the range (check local codes and manual).

• Round or rectangular duct compatibility – works with 3¼" x 10" rectangular ducting and optional round duct transitions for easier connection to existing vents.

• Horizontal or vertical duct discharge – supports both wall and roof/ceiling venting configurations to match your home’s duct layout.

• Optional 3¼" x 10" to 6" round duct transition (model 411) – accessory allows connection to 6" round ducting where required.

• Optional 7" round damper (model BP87Q) – accessory damper helps control backdrafts and maintain proper airflow in round-duct installations.

• Optional 7" round adapter plate (model SR680508) – adapter plate simplifies mounting and connection to 7" round duct systems.

• Non-ducted recirculation capable – can be installed without exterior venting, recirculating filtered air back into the kitchen when ducting is not feasible.

• Standard under-cabinet installation – mounts beneath most 24" cabinets, ideal for replacement of older hoods in the same size class.

• Economy category value – designed as a budget-friendly solution that still offers multi-speed ventilation and lighting.

• 1-year limited parts and labour warranty – manufacturer-backed coverage provides peace of mind against defects in materials and workmanship.

• Compact width class (24") – sized for smaller apartments, condos, secondary suites or compact kitchens where space is limited.

• Improves kitchen air quality – helps reduce lingering cooking odours, smoke and airborne grease for a fresher kitchen environment.

• Protects cabinets and surfaces – capturing grease and steam helps minimize residue buildup on nearby cabinets, walls and ceilings.

• Enhances cooking comfort – removes excess heat and humidity from the cooking area, making the kitchen more comfortable during meal prep.

• Simple, intuitive controls – basic rocker switches are easy for all users to understand and operate without a learning curve.

• Ideal for rentals and multi-unit housing – durable, economical design and straightforward operation make it suitable for apartments and rental properties.
