Electrolux Icon E23BC78IPS Counter Depth French Door Refrigerator, 36 in, 22.6 cu.ft, with 4 Custom-Design Glass Shelves, Clear Gallon Adjustable Door Bin, Custom Temp Drawer, PureAdvantage Filtration System and Custom-Design Organization System
Custom Temp Drawer™
Enjoy the ultimate in versatility with 9 preset selections including White/Sparkling Wine, Fish/Shellfish, Cheese plus three customizable settings that ensure foods stay at the ideal temperature for serving and maintaining freshness.
Custom-Design™ Organization System
With our flexible Tri-Level freezer organization system you can keep your freezer well organized. The three Smooth-Glide ® baskets with removable dividers and top removable baskets allow you to configure the space to neatly fit large and small items.
Theatre Lighting
Transition LED lighting gradually illuminates the interior with soft but ample light as you open the door.
PureAdvantage ® Filtration Systems
Our filtration system keeps clean, filtered air circulated throughout to prevent odor transfer and keeps fresh, clean water and ice at your fingertips.
- Custom Temp Drawer™
- Enjoy the ultimate in versatility with 9 preset selections including White/Sparkling Wine, Fish/Shellfish, Cheese plus three customizable settings that ensure foods stay at the ideal temperature for serving and maintaining freshness.
- Custom-Design™ Organization System
- With our flexible Tri-Level freezer organization system you can keep your freezer well organized. The three Smooth-Glide baskets with removable dividers and top removable baskets allow you to configure the space to neatly fit large and small items.
- Theatre Lighting
- Transition LED lighting gradually illuminates the interior with soft but ample light as you open the door.
- PureAdvantage Filtration Systems
- Our filtration system keeps clean, filtered air circulated throughout to prevent odor transfer and keeps fresh, clean water and ice at your fingertips.
Custom Temp Drawer
Features 9 preset selections including White/Sparkling Wine, Fish/Shellfish, Snacks and Chilled Beer
Three customizable "My Favorites", giving you an array of choices to store or serve whatever you want at the ideal temperature.
Custom-Design Organization System
The tri-level freezer organization system features three Smooth-Glide baskets with removable dividers and top removable baskets, so you can keep food organized and easily at hand.
Twice the Ice
You get filtered, restaurant-quality ice featuring a new drink-friendly shape, twice the ice as any refrigerator ice maker - up to 9 pounds in 24 hours.
PureAdvantage Filtration Systems
The filtration system keeps clean, filtered air circulated throughout to prevent odor transfer and keeps fresh, clean water and ice at your fingertips.
Manufacturer's Warranty: 1 year
Canadian model: E23BC78IPS
Canadian UPC: 012505746345
EAN: 0012505746345
| Capacities | |
| Freezer Capacity (Cu. Ft.) | 6.86 |
| Freezer Shelf Area (Sq. Ft.) | 7.72 |
| Fresh-food Capacity (Cu. Ft.) | 15.68 |
| Fresh Food Shelf Area (Sq. Ft.) | 18.71 |
| Capacity (Cu. Ft.) | 22.5 |
| Total Shelf Area (Sq. Ft.) | 26.43 |
| Certifications & Approvals | |
| CSA Certified | Yes |
| ENERGY STAR ® Certified | No |
| Sabbath Mode (Star-K ® Certified) | Yes |
| Fresh Food | |
| Air Filter Location | Left Fresh Food Door |
| Air Filter | PureAdvantage ® |
| Door Ajar Alert | Yes |
| Temperature Alert | Yes |
| Power Failure Alert | Yes |
| Crispers | 2 Smooth-Glide ® |
| Dairy Compartment | Clear Locking |
| Half-Gallon Door Bins | 1 Clear (Adjustable) |
| Tilt-Out Door Bins | 2 Clear (1 per door) |
| Meat / Deli Drawer | Custom Temp Drawer™ |
| Drawer Trims | Yes |
| Drawer Trim Color | White & Silver |
| Energy Saver Plus | Yes |
| Humidity Controls | 2 |
| Lighting Levels | Dual-Level |
| Luxury-Design ® Ramp-Up Multilevel Lighting | Theatre Ramp-Up LED |
| Cantilever Shelves | Yes |
| Custom-Design™ Shelves | 3 Half-Width 1 Quarter-Width |
| Water Filter Location | Bottom/Left Fresh Food Section |
| Water Filter | PureAdvantage ® |
| Controls | |
| Control Location | Dispenser |
| Controls | Wave-Touch ® |
| Air Filter Indicator / Reset | Yes |
| Supplemental Freeze | Fast Freeze™ |
| System On/Off Control | Yes |
| Water Filter Indicator / Reset | Yes |
| General Specifications | |
| Condenser Type | Dynamic |
| Water Inlet Location | Left Rear Bottom |
| Sound Package | Luxury-Quiet™ |
| Shipping Weight (lbs) | 341 |
| Freezer Specifications | |
| Lower Adjustable Basket Dividers | Yes |
| Middle Adjustable Basket Dividers | Yes |
| Upper Adjustable Basket Dividers | Yes |
| Lower Basket Construction | Wire grey powder-coated |
| Middle Basket Construction | Wire grey powder-coated |
| Upper Basket Construction | Wire grey powder-coated |
| Lower Basket Design | Smooth-Glide ® Full-Width |
| Middle Basket Design | Full-Width Smooth-Glide ® |
| Upper Basket Design | Full-Width Smooth-Glide ® |
| Ice Maker | |
| Ice Maker Bucket | Yes |
| Ice Maker Location | Fresh Food Section |
| Ice Maker | Yes |
| Ice Maker On/Off | Yes |
| Ice Maker Type | Fresh Food Ice Maker |
| Exterior Dimensions | |
| Case Depth | 23-7/8" |
| Depth (with Door 90° Open) | 42-1/2" |
| Depth with Doors (no Handles) | 27-1/8" |
| Depth with Doors and Handles | 29-5/8" |
| Height | 69-7/8" |
| Case Height | 68-5/8" |
| Height with Hinges and Covers | 69-7/8" |
| Width | 36" |
| Case Width | 35-7/8" |
| Exterior Specifications | |
| Cabinet Color | Stainless-Look |
| Door Closers | Yes |
| Door Design | Tall |
| Door Gasket | White |
| Door and Handle Design | Professional Stainless Steel |
| Door Hinge Covers | Hidden |
| Door Stops | Yes |
| Door Style | Square Corner |
| Name Badge | Electrolux ICON |
| Front Rollers | Yes |
| Rear Rollers | Yes |
| Toe Grille | Stainless Steel |
| Door Finish | |
| Exterior Specifications | Stainless Steel |
| Electrical Specifications | |
| Amps @ 120 Volts | 8.5 |
| Minimum Circuit Required (Amps) | 15A |
| Connected Load (kW Rating) @ 120V | 1.02 |
| Power Supply Connection Location | Right Rear Bottom |
| Voltage Rating | 120V 60Hz |
| Capacities | |
| Total Capacity: | 22.6 Cu.Ft. |
| Fresh Food Volume: | 15.7 Cu.Ft. |
| Freezer Volume: | 6.9 Cu. Ft. |
| Total Shelf Area: | 26.45 Sq.Ft. |
| Fresh Food Shelf Area: | 18.72 Sq.Ft. |
| Freezer Shelf Area: | 7.7 Sq.Ft. |
| Exterior | |
| Professional Doors and Handle Design: | Yes |
| Wave-Touch Electronic Controls: | Yes |
| Door Hinge Covers: | Yes |
| Ice/Water Dispenser: | Yes |
| Custom-Set Temperature Control System and Display: | Yes |
| Crushed/Cubes/Water: | Yes |
| Air and Water Filter Indicator/Reset: | Yes |
| Ice Maker On/Off: | Yes |
| Fast Freeze: | Yes |
| Lock: | Yes |
| Dispenser Light Control: | Yes |
| Fresh Food Conveniences | |
| PureAdvantage Water and Ice/Air Filtration: | Yes |
| Water Filter Location: | Bottom Left |
| Temp Alarm System/Door Ajar Alarm/Power Failure Alarm: | Yes |
| Custom-Design Glass Shelves: | 3 Half Width 1 Quarter Width |
| Smooth-Glide Humidity-Controlled Left Crisper: | Yes |
| Smooth-Glide Humidity-Controlled Right Crisper: | Yes |
| Custom Temp Drawer: | Yes |
| Wine Rack: | Yes |
| Clear Gallon Adjustable Door Bins: | 1 |
| Clear 1/2-Gallon Adjustable Door Bins: | 1 |
| Clear 2-Liter/1/2-Gallon Removable Door Bins: | 2 |
| Locking Clear Utility Bin: | Yes |
| Tilt-Out Can Racks: | 2 |
| Theater Ramp-Up Multilevel Lighting - LED: | Yes |
| Automatic Ice Maker: | Yes |
| Freezer Conveniences | |
| Self-Closing Drawer: | Yes |
| Sliding Full-Width Freezer Baskets: | 3 Smooth-Glide (2 with Dividers) |
| Plastic Basket Tray: | 1 |
| Tilt-Out Wire Door Racks: | 1 |
| Theater Ramp-Up Multilevel Lighting - LED: | Yes |
| Additional Features | |
| ENERGY STAR: | Yes |
| Sabbath Mode (Star-K Certified): | Yes |
| A.D.A. Compliant: | Yes |
| Specifications | |
| Width: | 35 5/8" |
| Depth Including Handle: | 29 1/2" |
| Depth with 90° Doors Open: | 42 9/16" |
| Depth with Drawer Fully Extended: | 44 1/2" |
| Height (with Hinges and 3/8" Rollers): | 69 1/2" |
| Approx. Shipping Weight: | 341 Lbs. |
| Power/Ratings | |
| Power Supply Connection Location: | Right Bottom Rear |
| Water Inlet Location: | Left Bottom Rear |
| Voltage Rating: | 120V/60Hz/15 or 20A |
| Connected Load @120 Volts: | 1.02 kW |
| Minimum Circuit Required: | 15 A |
Complete Owner's Guide (English) (E23BC78IPS-complete-owners-guide-english-1.pdf)
