CGEF3055KW Frigidaire Electric Range 30 inch Canada Parts

Frigidaire Gallery CGEF3055KW Freestanding Range, 6.0 Cu. Ft., 30" Electric, Auto Shut-Off, Quick Clean Option, Smoothtop Ceramic Glass Cooking Surface, 1x6/9” 3000w Element w/Quick Boil, 1x9/12” 2700w SpaceWise™ Element, 2x6” 1200w Elements, 1xKeep Warm Zone (100 W), One Touch Options - Chicken Nuggets, Pizza, Keep Warm, One-Touch Self Clean, Delay Start, 8 Pass Bake Element 3500w, 6 Pass Broil Element 3900w, Quick PreHeat, True Hidden Bake Element, Quick Preheat, True Convection w/350 watt element, 1 Oven Light, 1 Effortless Oven Rack, 1 Spacewise™ Half Rack, Wide-View Window w/Tint (F/B), Storage Drawer, Star-K® Certified.

Fits-More™ Oven
A unique rack configuration creates more cooking space.

Quick Preheat
Pre-heat in less than 6 minutes.

True Convection
With True Convection, you can easily and evenly bake 200 chicken nuggets in 10 minutes².

Quick Boil
Boils water fast.

Chicken Nugget Button
Easily bake perfect chicken nuggets with the touch of a button.

Pizza Button
Easily bake perfect pizza at the touch of a button.

SpaceWise™ Half Rack
Flexible rack system that adjusts to cook multiple dishes at once. Remove the half rack and you’ll have extra height for tall dishes.

Effortless™ Oven Rack
Bottom rack extends when you open the door for easy access.

Real Stainless Steel
Real stainless steel with a protective coating that reduces fingerprints and smudges so it's easy to clean.

Effortless™ Convection
Takes the guesswork out of convection cooking - our oven does the converting for you.

Even Baking Technology
Our latest technology ensures even baking every time.

Add-a-Minute
Easily add a minute to the oven timer in the middle of a cycle without resetting.

Auto Shut-Off
As an extra safety measure, the oven will automatically shut off after 6 hours.

Power Broil
Added power means you can broil food more evenly.

Quick Clean
For a quick, light oven cleaning.

Delay Start
Set your oven to begin cooking on your schedule. It can be programmed from 1 to 24 hours.

SpaceWise™ Expandable Elements
Flexible elements expand to your cooking needs.

Manufacturer's Warranty: 1 year

Canadian model: CGEF3055KW

Specs

Base_Model	CGEF3055K
Installation Type	Free-Standing
Power Type	Electric
Colour	White
Sabbath Mode (Star-K® Certified)	Yes
Exterior Finish	Painted
Exterior Door Finish	Glass
Control Panel
Interface	Membrane
Knobs	Weighted
Delay Bake	Yes
Broil	Broil Variable (400 - 500 °F)
Convection Bake	Yes
Convection Broil	Yes
Convection Roast	Yes
Convection Conversion	Yes
Preheat	Integrated with Bake
Quick Preheat	Yes
Keep Warm	Yes
Chicken Nugget Button	Yes
Pizza Button	Yes
Self-Clean	2, 3, 4 Hours (Scroll thru)
Delay Clean	Yes
Add-a-Minute	Yes
Delay Start	Yes
Timed Shut-off	6 hrs.
Timer Function	Yes
Oven Lock-out	Yes
Timer Lock-out	Yes
Cooktop Configuration
Surface Type	Upswept Black Smoothtop
Front Right Element	12"/9" 2700 watts
Front Left Element	9"/6" 3000 watts
Rear Right Element	6" 1200 watts
Rear Left Element	6" 1200 watts
Centre Element	Warming Zone
Oven Features
Capacity (Cu. Ft.)	6.0 Cu. Ft.
Bake Element (Watts)	3500
Baking System	Even Baking Technology
Broil Element (Watts)	3900
Broiling System	Power Broil
Convection Conversion	Yes
Convection System	True Convection
Hidden Bake Element	Yes
Rack Configuration	1 HD, 1xSpaceWiseMC 1/2 Rack, 1 EffortlessMC rack, 1 Deep Sump
Light Type	Standard
Light (No.)	1
Cleaning System	Self-Clean
Self-Cleaning Time	2, 3, 4 Hours (Scroll thru)
Window	Wide View
Drawer Features
Lower Drawer Controls	Storage
Drawer Functionality	Storage
Handle	New Gallery Metal - White
Oven Interior Dimensions
Interior Width	24-3/8"
Interior Depth	19-1/8"
Interior Height	22-1/4"
Exterior Dimensions
Exterior Width	29-7/8"
Exterior Depth	28-1/2"
Exterior Depth (to Center of Arc)	28-1/2"
Exterior Depth (with 90° Door Open)	48-3/8"
Exterior Height	47"
Power Supply Connection Location	Centreline Lower Rear
Connected Load (kW Rating) @ 240 / 208 Volts	12.5 / 9.5 kW
Voltage Rating	240 / 208 V
Minimum Circuit Required (Amps)	40
Product Weight	185 lbs
Shipping Weight (Approx.)	205 lbs
Size	30"
UPC Code	0-12505-50213-2

Installation Type: Free-Standing

Power Type: Electric

Colour: Stainless Steel

Sabbath Mode Certified: Yes

Exterior Finish: Real Stainless Steel

Exterior Door Finish: Real Stainless Steel

Control Panel

Interface: Membrane

Knobs: Cast

Delay Bake: Yes

Broil: Broil Variable (400 - 500 °F)

Convection Bake: Yes

Convection Broil: Yes

Convection Roast: Yes

Convection Conversion: Yes

Preheat: Integrated with Bake

Quick Preheat: Yes

Keep Warm: Yes

Chicken Nugget Button: Yes

Pizza Button: Yes

Self-Clean: 2, 3, 4 Hours (Scroll thru)

Delay Clean: Yes

Add-a-Minute: Yes

Delay Start: Yes

Timed Shut-off: 6 hrs.

Timer Function: Yes

Oven Lock-out: Yes

Timer Lock-out: Yes

Cooktop Configuration

Surface Type: Upswept Black Smoothtop

Front Right Element: 12"/9" 2700 watts

Front Left Element: 9"/6" 3000 watts

Rear Right Element: 6" 1200 watts

Rear Left Element: 6" 1200 watts

Centre Element: Warming Zone

Oven Features

Capacity: 6.0 Cu. Ft.

Bake Element (Watts): 3500

Baking System: Even Baking Technology

Broil Element (Watts): 3900

Broiling System: Power Broil

Convection Conversion: Yes

Convection System: True Convection

Hidden Bake Element: Yes

Rack Configuration: 1 HD, 1xSpaceWiseMC 1/2 Rack, 1 EffortlessMC rack, 1 Deep Sump

Light Type: Standard

Light (No.): 1

Cleaning System: Self-Clean

Clean Time: 2, 3, 4 Hours (Scroll thru)

Window: Wide View

Drawer Features

Lower Drawer Controls: Storage

Drawer Functionality: Storage

Handle: New Gallery Stainless

Oven Cavity Dimensions

Interior Width: 24-3/8"

Interior Depth: 19-1/8"

Interior Height: 22-1/4"

Exterior Dimensions

Exterior Width: 29-7/8"

Exterior Depth: 28-1/2"

Depth (to Center of Arc): 28-1/2"

Exterior Depth (Door Open 90°): 48-3/8"

Exterior Height: 47"

Power Supply Connection Location: Centreline Lower Rear

Connected Load (kW Rating) @ 240 / 208 Volts: 12.5 / 9.5 kW

Voltage Rating: 240 / 208 V

Minimum Circuit Required (Amps): 40

Product Weight: 185 lbs

Shipping Weight: 205 lbs

Manuals

Frigidaire / Electrolux Ranges 2024

Owners Manual English (CGEF3055KW-owners-manual-english-canada.pdf)

Fran?ais (CGEF3055KW-francais-canada.pdf)

All Languages (CGEF3055KW-all-languages-canada.pdf)
