General Specifications
Decibel level (dB)	56
Leveling Legs	4
Product Weight (lbs)	65
Power Type	Electric
Size	24''
Installation Type	Built-In
Collection	Frigidaire Frigidaire
Dishwasher: Options
Hi-Temp Wash	Yes
Heat/No Heat Dry	Yes
Dishwasher
Capacity	12
Tub Design	Tall-Tub Design
Interior	Stainless Steel
Filter	Stainless Steel
Food Disposer	Stainless Steel
Filter Cleaning Type	Self Cleaning
Dimensions: Cut-Out
Depth	24"
Height	32 1/2 - 35 1/4
Width	24"
Certifications & Approvals
ENERGY STAR® Certified	Yes
ADA Compliant - All Brands	Yes
Cycles
Pots and Pans	Yes
Dishwasher Specifications
Rinse Aid Dispenser	Adjustable with Indicator
Smart Soil Sensor	No
Wash Levels	5
Wash System	Direct Feed
Controls
Delay Start - hours	1 - 24 Hours
Upper Rack
Folding Bowls Tines	Yes
Stemware / Champagne Glass Holders	Yes
Upper Rack Type	Deluxe
Electrical Specifications
Amps @ 120 Volts	10
Power Supply Connection Location	Front Right Bottom
Voltage Rating	120V 60Hz
Dishwasher: Cycles
Number of Cycles	5
Energy Saver	Yes
China Crystal	Yes
Normal	Yes
Rinse Only	Yes
Rack System
Rack Type	Pearl Grey Nylon-Coated TufRacks
Exterior Dimensions
Depth	24
Depth (with Door 90° Open)	44.5
Height	32-1/2" - 35 1/4"
Height (Min.)	32-1/2"
Width	24"

Features
ENERGY STAR:	Yes
ADA Compliant:	Yes
Size/Type:	24" Built-In
BIG Tub Design:	Yes
Control Type:	Electronic
Console Type:	Upswept
Easy-Clean Pads/Pushbuttons:	9 Electronic
Wash Levels:	5
Wash System:	Direct-Feed Wash
Direct-Feed Water Delivery:	Yes
Self-Cleaning Filter:	Stainless Steel
Removable Filter Trap:	Yes
Stainless Steel Food Disposer:	Yes
Sound Insulation Package:	SilentDesign
Dry System:	Static Vent
Detergent Dispenser:	Yes
Rinse-Aid Dispenser with Indicator:	Adjustable
Controls Lock:	Yes
Cycles
Pots and Pans:	Yes
Normal:	Yes
Energy-Saving Wash:	Yes
China/Crystal:	Yes
Rinse Only:	Yes
Options
Heat/No Heat Dry:	Yes
Hi-Temp Wash:	Yes
Delay Start:	1 - 24 Hours
Rack System
Upper Rack:	Deluxe
Upper Rack - Cup Shelf:	2
Upper Rack - Stemware Holder:	Yes
Lower Rack:	Deluxe
Lower Rack - Rack Type:	Nylon TufRack
Lower Rack - Silverware Basket:	3-Piece Split
Lower Rack - Small Items Cover:	3
Specifications
Leveling Legs:	Yes
Water Usage:	5.4 Gals. (Normal Cycle)
Water Pressure:	20 - 120 PSI
Volts:	120V
Amps:	7A (Separate 15A 3-Wire Grounded Circuit Required)
Watts (Heating Element):	630 Watts
Shipping Weight:	69 Lbs.
Dimensions
Overall Width:	24"
Overall Depth:	20 1/2"
Overall Depth with Door:	23"
Overall Depth with Door 90°:	46"
Overall Height:	32 1/2" Min. to 34 7/8" Max.
Cutout Width:	24" Min.
Cutout Depth:	24" Min.
Cutout Height:	32 1/2" Min. to 35 1/4" Max.

Frigidaire FDB2410HIS

Frigidaire FDB2410HIS Dishwasher, 5 Wash Cycles, 12 Capacity (Place Settings), 2 Loading Racks, White colour
