Frigidaire FFFS5115PA Washer
The modern design of the front-load Frigidaire FFFS5115PA washer upgrades any home laundry room with style and performance. Its large 4.5 cubic foot capacity wash basket allows users to wash up to two full laundry baskets of clothes in a single load, saving time and energy. Frigidaire allows the user to customize the washer’s performance through the use of 10 wash cycles and several wash options. With steam technology and advance rinse technology, cleaning heavily soiled fabrics is easier than it was with your old washer. If you are looking for a beautiful, high-performance washing machine for your home, there is no better choice than this Frigidaire.
The front load design of the stainless steel Frigidaire FFFS5115PA washing machine adds a flair of style to your laundry room while delivering near professional cleaning results. When the beautiful chrome-trimmed, door is opened, a large 4.5 cubic foot capacity stainless steel wash basket is exposed. Its smooth, durable stainless steel wash basket will not rust, crack, chip or snag fabrics, providing the ultimate fabric care.
Its large wash capacity allows you to wash two full laundry baskets of clothes in a single load. With this Frigidaire washing machine enables you to spend less time doing laundry, and more time with your family.
This high-performance washing machine makes it possible to customize the performance of each wash load through 10 wash cycles and several wash options, The wash cycles include bedding, casual, delicates, hand wash, heavy, normal, quick cycle, spin only, and whitest whites. Its wash options include add steam, clean washer, delay start, energy saver, freshwater rinse, mix fill, and stain clean.
The quick wash cycle is perfect for small, lightly soiled loads, allowing you to achieve the same great performance as with other cycles. With this Frigidaire, you can wash small loads of clothes in as little as 20 minutes, allowing you to clean your clothes and be on your way.
Frigidaire’s wash options include an add steam function. Adding steam to a wash cycle improves the stain removal ability, penetrating deep into fabrics, lifting stains where hide.
The advance rinse technology uses fresh water in the final rinse cycle, achieve whiter whites while reducing allergens left behind in fabrics.
Frigidaire takes the wash performance to the next level with the tumble action cleaning system. The tumble action cleaning system removes the agitation elements, tumbling clothes gently to achieve a complete clean and thorough rinse. This enhanced fabric care allows your clothes to feel fresher and last longer than before.
The Frigidaire FFFS5115PA is both Energy Star and CEE Tier 3 certified. Energy Star and CEE Tier 3 appliances are among the most energy efficient household appliances available on the market, exceeded strict energy consumption guidelines by a minimum of 35%.
With the Frigidaire FFFS5115PA, you can do your part to help reduce the carbon imprint of home appliances on the environment while lowering your utility bills and achieving near professional level cleaning results.
Frigidaire FFFS5115PA 27 in Front-Load Washer with 4.5 cu. ft. Capacity, 10 Wash Cycles, NSF Certified Cycle, Steam Option, Internal Water Heater and Energy Star Tier 3
- Ready Steam
- Improves stain removal by adding steam to the cycle during the wash to help lift stains.
- Advance Rinse Technology
- Final rinse uses fresh water to ensure whiter whites and reduce allergens.
- Stainless Steel Drum
- Smooth, durable interior is rust-proof and won't snag clothes.
- Large-Capacity
- Finish more in less time with our 3.9 Cu. Ft. capacity - the washer can fits two baskets of laundry in a single load.
- Tumble Action Cleaning System
- By removing the agitator, you can count on the tumble action to wash gently and rinse completely, ensuring your clothes feel fresher and last longer.
- ENERGY STAR®
- Stain Clean Option
- Delay Start
- Begin you washing cycle at the time that works best with your schedule.
- Ready-Select® Controls
- It's easy to get laundry started with just the touch of a button.
- End-Of-Cycle Signal
- TimeWise® Technology
- Wash time equals dry time - so you don't wait for clothes to dry.
- SilentDesign
- Designed for quiet operation.
- Stay-Fresh Antimicrobial Seal
- Auto Options
- Automatic Water Level Control
- Optional Pedestal Drawer
- Vibration Control System
- Advanced vibration control keeps even oversized loads balanced for smooth, quiet operation. Ideal for second floor installation.
- Save Your Settings
- Automatically save your last wash setting so you can save time when doing laundry.
- Cleaner, Fresher Laundry
- Advanced rinse technology incorporates a fresh water rinse for whiter whites, brighter colors and clothing that feels fresher.
Wash Cycles
10 Wash Cycles
5 Soil Level Selections
Energy Saver Option
Freshwater Rinse
Max Fill Option
NSF® Sanitize Certification
Quick Wash
Ready Steam Option
Stain Clean Option
Appearance
Chrome Door Trim
Front Load Design
Stainless Steel Tub
Viewing Window
Dimensions
36" H x 30 5/16" D x 27" W
Controls
Cycle Status Lights
Door Lock Light
Ready-Select™ Controls
Start/Pause/Cancel Buttons
Time Remaining Indicator
Manufacturers Warranty
1 Year Limited Parts & Labor
Limited Lifetime Warranty-Tub
Washing System
1200 RPM Spin Speed
5 Spin Speeds
5 Wash Temperatures
Advanced Rinse Technology
Automatic Temperature Control
Automatic Water Level
TimeWise™ Technology
Tumble Action Wash System
Capacity
3.9 Cu Ft DOE Capacity
Convenience Features
16 Hour Delay Start
Auto Bleach Dispenser
Auto Detergent Dispenser
Auto Fabric Softener Dispenser
Stay Put Door
Stay-Fresh Door Seal
Additional Features
Integral 1000W Water Heater
Option-15" White Drawer Pedestal (PN # CFPWD15W)
Option-Dryer Stacking Kit (PN # Stackit4X)
Option-Mobile Home Installation Kit (PN#137067200)
Vibration Control System
Energy/sound/power
Energy Star®
SilentDesign™ Quiet Operation
Additional Dimensions
27" Minimum Space
Manufacturer's Warranty: 1 year
Canadian model: FFFS5115PA
Canadian UPC: 012505385728
EAN: 0012505385728
| General Specifications | |
| Leveling Legs | Yes |
| Product Weight (lbs) | 235 |
| Power Type | Electric |
| Size | N/A |
| Installation Type | Free-Standing |
| Collection | Frigidaire |
| Washer: Options | |
| Add Steam | Yes |
| Allergy | No |
| Clean Washer | Yes |
| Delay Start (Hours) | Yes |
| Energy Saver | Yes |
| Extended Spin | No |
| Freshwater Rinse | Yes |
| Light | No |
| Max Fill | Yes |
| Prewash | No |
| Stain Clean | Yes |
| Stain Pretreat | No |
| Washer: Specifications | |
| Bleach Dispenser | Yes |
| Detergent Dispenser | Yes |
| Drum Light | No |
| Drum Material | Stainless Steel |
| Fabric Softener Dispenser | Yes |
| Internal Water Heater | Yes |
| Maximum Spin Speed (RPM) | 1200 |
| Prewash Detergent Dispenser | No |
| Stay Fresh Antimicrobial Seal | Yes |
| Stay Fresh Door Seal | Yes |
| Energy Data | |
| CEE Tier Level | 0 |
| Certifications & Approvals | |
| ENERGY STAR® Certified | Yes |
| ENERGY STAR® Most Efficient | No |
| NSF® Certified | Yes |
| High Efficiency | Yes |
| Washer: Soil Level Selections | |
| Extra Light Soil | Yes |
| Heavy Soil | Yes |
| Light Soil | Yes |
| Max Soil | Yes |
| Normal Soil | Yes |
| Exterior Dimensions | |
| Depth | 30-3/10" |
| Depth (with Door 90° Open) | 51-2/5" |
| Height | 36" |
| Width | 27" |
| Accessories | |
| Drain Hose Extension Kit | Optional order item no. 137098000 |
| Dryer Stacking Kit | Optional order item no. STACKIT4X |
| Mobile Home Installation Kit | Optional order item no. 137067200 |
| Pedestal | Optional order item no. CFPWD15 |
| Washer: Specialty Cycles | |
| Active Wear | No |
| Jeans | No |
| Kids Wear | No |
| Pet Beds | No |
| Quick Sanitize | No |
| Stuffed Animals | No |
| Washer: Temperature Settings | |
| Automatic Temperature Control | Yes |
| Cold | Yes |
| Cold Water Clean | Yes |
| Cool | No |
| Hot | Yes |
| Sanitize | Yes |
| Warm | Yes |
| Electrical Specifications | |
| Amps @ 120 Volts | 10 |
| Connected Load (kW Rating) @ 120V | 1.1 |
| Minimum Circuit Required (Amps) | 15A |
| Power Supply Connection Location | Rear |
| Voltage Rating | 120V 60Hz |
| Watts @ 120 Volts | 1100 |
| Energy Data | |
| Integrated Modified Energy Factor (ft3/kwh/cycle) | 2.44 |
| Washer: Cycles | |
| Allergen | No |
| Bedding | Yes |
| Casual | Yes |
| Delicates | Yes |
| Hand Wash | Yes |
| Heavy | Yes |
| Heavy/Bulky | No |
| Normal | Yes |
| Quick Cycle | Yes - 20 minutes |
| Rinse & Spin | No |
| Spin Only | Yes |
| Whitest Whites | Yes |
| Controls | |
| Control Lock | Yes |
| Cycle Status Lights | Yes LCD |
| Time Remaining Indicator | Yes LCD |
| Start/Pause/Cancel Function | Push 'Start/Pause' button to Start / Push 'Start/Pause' button to Pause / Push 'Cancel' button to Cancel |
| Exterior Specifications | |
| Cabinet Color | White |
| Console Color | White |
| Door Lock Light | Yes LED |
| Door Style | Affinity |
| Knob Button Switch Color | Chrome |
| Lens Ring | Chrome |
| Features | |
| Total Capacity D.O.E.: | 3.9 Cu. Ft. |
| Controls: | Ready-Select |
| Washer Drum Interior: | Stainless Steel |
| Lifetime Warranty Tub: | Yes |
| Interior Light: | No |
| Door Trim: | Chrome |
| Vibration Control System: | Yes |
| Advanced Rinse Technology: | Yes |
| TimeWise Technology: | Yes |
| Ready Clean: | No |
| Ready Steam: | Option |
| Fresh Water Rinse Option: | Yes |
| Stay-Fresh Door Seal: | Yes |
| Temperature Control: | Automatic |
| Water Level Adjustments: | Automatic |
| Auto Prewash Detergent Dispenser: | No |
| Auto Bleach Dispenser: | Yes |
| Auto Detergent Dispenser: | Yes |
| Auto Fabric Softener Dispenser: | Yes |
| Time Remaining Indicator: | Yes |
| Cycle Status Lights: | Yes |
| Cycle Signal: | Chime |
| Cycle Signal "On/Off": | Yes |
| Cycle Signal Volume Control: | No |
| Door Lock Indicator Light: | Yes |
| Control Lock: | Yes |
| Stay Put Door: | Yes |
| Start / Pause / Cancel Buttons: | Yes |
| Energy Saver Option: | Yes |
| Delay Start: | Up To 16 Hours |
| Integral Water Heater: | Yes, 1,000 Watts |
| Tumble Speed: | Variable |
| Spin Speed: | 1,200 Maximum RPM |
| Sound Package: | SilentDesign |
| Leveling Legs: | Adjustable |
| Cycles | |
| Wash Cycles: | 10 |
| Specialty Cycles: | 0 |
| Options | |
| Water Temperature Selections: | 5 |
| Water Levels: | Automatic / Max Fill |
| Spin Speed: | 5 |
| Soil Level Selections: | 5 |
| Allergen: | No |
| Certifications | |
| ENERGY STAR: | Most Efficient |
| NSF Certified Sanitize: | Yes |
| Allergen: | No |
| Specifications | |
| Power Supply Connection Location: | Right Top Rear |
| Water Inlet Connection Location: | Left Top Rear |
| Voltage Rating: | 120V / 60Hz / 15A |
| Connected Load (kW Rating) @ 120 Volts: | 1.1 kW |
| Watts @ 120 Volts: | 1,100 Watts |
| Amps @ 120 Volts: | 10 Amps |
| Minimum Circuit Required: | 15 Amps |
| Dimensions and Weights | |
| Overall Width: | 27" |
| Overall Depth: | 30 5/16" |
| Overall Depth with Door Open 90°: | 51 7/16" |
| Overall Height: | 36" |
| Overall Height (Stacked): | 71 1/2" |
| Pedestal Width: | 27" |
| Pedestal Depth: | 26 1/2" |
| Pedestal Height: | 15 1/4" |
| Depth with Drawer Fully Extended: | 42 1/2" |
| Shipping Weight (Approx.): | 222.0 Lbs. |
Complete Owner's Guide (English) (FFFS5115PA-complete-owners-guide-english-canada.pdf)
