Frigidaire FFGF3053LS Freestanding Gas Range 5 cu.ft, 30 in, with 4 Sealed Burners, Quick Boil Burner, Ready-Select Controls and Store-More Storage Drawer
- One-Touch Self Clean
- Your oven cleans itself - so you dont have to. Self clean options available in 2, 3 and 4-hour cycles.
- Quick Boil
- Get meals on the table faster with our 14,000 BTU burner - water boils faster than the traditional setting.
- Store-More Storage Drawer
- With the Store-More Storage Drawer, you will have extra space to store your cookware.
- Delay Clean
- Set the oven to begin cleaning on your schedule.
- Large Capacity
- Our large capacity oven gives you room to cook more dishes at once.
- Color-Coordinated Oven Door with Large Window
- Our large oven window makes it easier to check on the status of your dish without having to open the oven door.
- Sealed Gas Burners
- Enjoy easier cleanup and a burner that stays looking great.
- Ready-Select® Controls
- Easily control your cooking temperature with our easy-to-use controls.
- Matte Black Finish with Cast Iron Grates
- A premium finish to complement the durable burner grates.
- Low Simmer Burner
- Perfect for cooking delicate foods and sauces.
Large Capacity
Our large capacity oven gives you room to cook more at once.
Ready-Select® Controls
Select options or control cooking temperature with our easy-to-use controls.
Built with American Pride
Appliances that are high-performing, more accessible, and more innovative than ever—designed, built, and engineered in the U.S.A.
Sealed Gas Burners
Enjoy easier cleanup and a burner that stays looking great.
Matte Black Finish with Cast Iron Grates
A premium finish to complement the durable burner grates.
Quick Boil
Boil water faster with our 14,000 BTU burner.
Low Simmer Burner
Perfect for delicate foods and sauces.
Store-More™ Storage Drawer
Our convenient drawer gives you extra storage space in your kitchen.
Manufacturer's Warranty: 1 year
Canadian model: FFGF3053LS
Canadian UPC: 012505502606
EAN: 0012505502606
| General Specifications | |
| Leveling Legs | 4 Adjustable |
| Product Weight (lbs) | 135 |
| Power Type | Gas |
| Size | 30'' |
| Installation Type | Free-Standing |
| Collection | Frigidaire |
| Cooktop Specifications | |
| Cooking Surface | Upswept / Sealed Burners |
| Grate Color | Black Matte |
| Grate Material | Cast Iron |
| Grates | Individual |
| Knob Color | Black |
| Knob Type | Plastic Black |
| Left Front | 9500 BTU |
| Left Rear | 9500 BTU |
| Right Front | 14000 BTU |
| Right Rear | 5000 BTU |
| Exterior Specifications | |
| Cooktop Finish | Black Porcelain |
| Drawer Finish | Black Metal with Stainless Steel Overlay |
| Exterior Finish | Painted |
| Manifold Panel | Black |
| Capacities | |
| Capacity (Cu. Ft.) | 5 |
| Certifications & Approvals | |
| ADA Compliant | No |
| Agency Approval | CSA |
| Sabbath Mode (Star-K® Certified) | No |
| Exterior Dimensions | |
| Height | 47-3/4" |
| Width | 29-7/8" |
| Depth | 28-13/32" |
| Door Finish | |
| Door Finish | Glass with Stainless Steel overlay |
| Cooking Controls | |
| Bake | Yes |
| Broil | Broil Variable (400 - 500°F) |
| Clear Button | Yes |
| Lockout | Yes |
| Lower Drawer Controls | Storage |
| Self-Clean | 2 3 Hours (Scroll thru) |
| Temperature Probe | No |
| Timed Cook Option | Yes |
| Timed Shut-off | 12 hours |
| Timer | Yes |
| Drawer | |
| Drawer Functionality | Storage |
| Handle | Stainless Steel |
| Handle Color | |
| Handle Color | Stainless Steel |
| Oven Specifications | |
| Oven 1 Bake | 18000 BTU |
| Oven 1 Baking System | Even Baking Technology |
| Oven 1 Broil | 13500 BTU |
| Oven 1 Broiling System | Vari-Broil High/Low |
| Oven 1 Cleaning System | Self-Clean |
| Oven 1 Interior Color | Slate Blue |
| Oven 1 Interior Depth | 19-1/8" |
| Oven 1 Interior Height | 18-5/8" |
| Oven 1 Interior Lighting | 1 Incandescent |
| Oven 1 Interior Width | 24-3/8" |
| Oven 1 Rack Configuration | 2 Standard |
| Oven 1 Rack Positions | 6 positions |
| Oven 1 Type | Main |
| Oven Window | Extra-Large Visualite® |
| Control Panel Finish | |
| Exterior Specifications | Black Metal with Stainless Steel Overlay |
| Electrical Specifications | |
| Power Supply Connection Location | Rear Centerline Lower |
| Voltage Rating | 120V 60Hz |
|
Dimensions & Weights |
|
|
Product Width: |
29 7/8" |
|
Product Depth: |
28 1/2" |
|
Product Depth with Door Open 90°: |
46 5/8" |
|
Product Height: |
47" |
|
Cutout Width: |
30" min. |
|
Cutout Depth: |
24" min. |
|
Cutout Height: |
36" stand. |
|
Main Oven Interior Width: |
24 3/8" |
|
Main Oven Interior Depth: |
19 3/4" |
|
Main Oven Interior Height: |
17 5/8" |
|
Approximate Shipping Weight: |
150 lbs. |
|
Oven Controls |
|
|
Bake/Broil: |
Yes/Low and High |
|
Add-a-Minute: |
No |
|
Delay Bake: |
Yes |
|
Rapid/Quick Clean Option: |
Quick |
|
Delay Clean: |
Yes |
|
Kitchen Timer/Timed Cook Option: |
Yes/Yes |
|
Auto Oven Shutoff: |
12 Hours |
|
Cooktop Features |
|
|
Right Front Burner: |
14,000 BTU |
|
Right Rear Burner: |
5,000 BTU |
|
Left Front Burner: |
9,500 BTU |
|
Left Rear Burner: |
9,500 BTU |
|
Center Burner: |
N/A |
|
Oven Features |
|
|
Main/Auxiliary Capacity: |
5.0 cu. ft. |
|
Oven Light: |
1 |
|
Hidden Bake Element: |
No |
|
Rack Configuration: |
2 Standard |
|
Baking System: |
Even Baking Technology |
|
Broiling System: |
Vari-Broil Hi/Lo |
|
Main Bake/Broil Burners: |
18,000/18,000 BTU |
|
Optional Accessories |
|
|
LP Gas Conversion Kit: |
PN# GRLP3 |
|
Specifications |
|
|
Power Supply Connection Location: |
Left Bottom Rear |
|
Gas Supply Connection Location: |
Right Bottom Rear |
|
Voltage Rating: |
120V / 60 Hz / 15 A |
|
Connected Load (kW Rating) @ 120 Volts: |
1.8 |
|
Amps @ 120 Volts: |
15 |
