Frigidaire Gallery Series FGBD2434PB Full Console Dishwasher with 14-Place Settings, 4 Wash Cycles, 5 Wash Levels, Stay-Put Door, Delay Start Option and 55 dBA
- Fan-Assisted Drying System
- No need to towel-dry.
- NSF® Certified
- Sanitize cycle removes 99.9% of common household bacteria.
- 2 - 6 Hour Delay Start
- Set your dishwasher to run on your schedule. It can be set to run 2, 4 or 6 hours in advance.
- Stay-Put Door
- The door stays put at whatever angle you open it for easy loading and unloading.
- Fits up to 14 place settings
- Cleans 14 place settings in one cycle.
- Filtration
- Removable, self-cleaning filter.
- Multiple-Cycle Options
- Features easy-to-use cleaning cycle options including Rinse Only, Heavy Clean and Upper Rack (feature varies by model).
- Polymer Tub
- Supports the drying process, keeping dishes dry the first time.
- Energy Saver Dry Option
- No heat dry option.
- Express-Select® Controls
- Easily select options with the touch of a button.
Quiet Dishwasher
Fits-More™ Capacity
Our large capacity, tall-tub dishwasher fits up to 14 place settings so you can wash even more at once.
Built with American Pride
Appliances that are high-performing, more accessible, and more innovative than ever—designed, built, and engineered in the U.S.A.
Effortless™ Dry
Get outstanding drying performance with Effortless™ Dry.
Energy Saver Dry Option
No heat dry option.
2-4-6 Hour Delay Start
Set your dishwasher to run on your schedule.
NSF® Certified
Sanitize cycle removes 99.9% of common household bacteria.
Multiple-Cycle Option
Features easy-to-use cleaning cycle options including Top Rack, Rinse Only and Heavy Wash.
Express-Select® Controls
Easily select options with the touch of a button.
Stay-Put Door
The door stays put at whatever angle you open it.
Low-Rinse Aid Indicator Light
High Temperature Wash
Manufacturer's Warranty: 1 year
Canadian model: FGBD2434PB
Canadian UPC: 012505113789
EAN: 0012505113789
| General Specifications | |
| Decibel level (dB) | 55 |
| Leveling Legs | 4 |
| Product Weight (lbs) | 67 |
| Power Type | Electric |
| Size | 24'' |
| Installation Type | Built-In |
| Collection | Frigidaire Gallery |
| Options | |
| NSF® Certified Sanitize Option | Yes |
| Hi-Temp Wash | Yes |
| Heat/No Heat Dry | Yes |
| Dishwasher Specifications | |
| Place Settings | 14 |
| Tub Design | Tall-Tub Design |
| Interior | White |
| Filter | Plastic |
| Food Disposer | Yes |
| Rinse Aid Dispenser | Adjustable with Indicator |
| Satellite Spray Arm | No |
| Wash Levels | 5 |
| Wash System | Direct Feed |
| Cut-Out Dimensions | |
| Cut-Out Depth | 24" |
| Cut-Out Height | 34-1/4" |
| Cut-Out Width | 24" |
| Certifications & Approvals | |
| ENERGY STAR® Certified | Yes |
| ADA Compliant | No |
| Rack System | |
| Rack Coating | Nylon TufRacks |
| Electrical Specifications | |
| Amps @ 120 Volts | 10 |
| Power Supply Connection Location | Front Right Bottom |
| Voltage Rating | 120V 60Hz |
| Controls | |
| Controls | Slimline |
| Control Lock | Yes |
| Delay Start (hours) | 2 - 4 - 6 Hours |
| Upper Rack | |
| Cup Shelf | 2 |
| Plate - Height Clearance | 8" |
| Rack Handles | Yes |
| Stemware / Champagne Glass Holders | Yes |
| Exterior Specifications | |
| Door Latch | Pull Latch |
| Door Type | Stay-Put |
| Cycles | |
| Number of Cycles | 4 |
| Heavy | Yes |
| Normal | Yes |
| Rinse Only | Yes |
| Upper Rack | Yes |
| Lower Rack | |
| Height Clearance | 11 |
| Exterior Dimensions | |
| Depth | 25" |
| Depth (with Door 90° Open) | 49-1/4" |
| Height | 33-1/2" - 35" |
| Height (Min.) | 33-1/2" |
| Width | 24" |
|
Performance |
|
|
Place Settings: |
14 |
|
Power Type: |
Electric |
|
Electrical Requirements: |
10A; 120V; 60Hz |
|
Features |
|
|
Number of Cycles: |
4; Heavy; Normal; Rinse Only; Hi Temp Wash |
|
NSF Certified Sanitize Option: |
Yes |
|
Wash Levels: |
5 |
|
Leveling Legs: |
4 |
|
Controls: |
Slimline; Control Lock |
|
Delay Start: |
2/4/6 Hours |
|
Heat/No Heat Dry Option: |
Yes |
|
Filter: |
Plastic |
|
Food Disposer: |
Yes |
|
Rinse Aid Dispenser: |
Adjustable with Indicator |
|
Upper Rack |
|
|
Cup Shelf: |
2 |
|
Plate Height Clearance: |
8" |
|
Rack Coating: |
Nylon TufRacks |
|
Stemware/Champagne Glass Holders: |
Yes |
|
Construction |
|
|
Installation Type: |
Built-In |
|
Door Latch: |
Pull Latch |
|
Door Type: |
Stay-Put |
|
Exterior Finish: |
Smude Proof |
|
Tub Design: |
Tall Tub |
|
Dimensions and Weight |
|
|
Product Width: |
24" |
|
Product Depth: |
25" |
|
Product Height: |
33 1/2"-35" |
|
Depth with Door Open 90 Degrees: |
49 1/4" |
|
Product Weight: |
67 Lbs. |
