Frigidaire Gallery FGEC3645PS Smoothtop Electric Cooktop 36 in, Smudge-Proof Stainless Steel with 5 Elements, SpaceWise Expandable Element, Hot Surface Indicators and Express-Select Controls
- Fits-More Cooktop
- The Fits-More cooktop features five elements so you can cook more at once.
- SpaceWise® Expandable Elements
- Flexible elements expand to your cooking needs.
- Express-Select® Controls
- Easily go from warm to boil.
- Ceramic Glass Cooktop
- For a more beautiful cooktop that's easy to clean.
- Hot Surface Indicators
- Approved Over Frigidaire® Electric Wall Ovens
- Cooktops are approved for installation above any of our Single Electric Wall Ovens.
36in Electric Cooktop, Ceramic Glass Surface, Right Side Controls, Hot Surface Indicator Light, 1x12 2700w Element, 1x6/9" 3000w Space Wise Expandable, 1x7 1500w Element, 2x6 1200w Element, Bevelled Edges on Non Trimmed Sides, Approved For Single Oven Combination Installation. Back Cooktop With One Stanless Steel Trim & Black Plastic Knobs. Power Connection Location: Rear Right Connected Load (Kw Rating) @ 240/208 Volts: 9.6/7.2 kW Amps: 40/35 Amps Minimum Circuit Requirement: 40 Amps Voltage Rating: 240/208V/60Hz.
Manufacturer's Warranty: 1 year
Canadian model: FGEC3645PS
Canadian UPC: 057112991283
EAN: 0057112991283
| General Specifications | |
| ProductLaunch | NA |
| Reconditioned | No |
| Shipping Weight (lbs) | 65 |
| Product Weight (lbs) | 60 |
| Power Type | Electric |
| Size | 36'' |
| Installation Type | Drop-In |
| Collection | Frigidaire Gallery |
| Controls | |
| Control Location | Right Side |
| Control Type | Mechanical |
| Dimensions: Exterior | |
| Height | 2-5/8" |
| Width | 36-3/4" |
| Depth | 21-3/8" |
| Cooktop | |
| Cooking Surface | Black Ceramic Glass |
| Warming Zone | No |
| Right Front | 6/9" - 1600/3000 Watts |
| Right Rear | 7" - 1500 Watts |
| Knob Type | Cast Metal |
| Left Rear | 6" - 1200 Watts |
| Knob Color | Stainless Steel |
| Left Front | 12" - 2700 Watts |
| Cooktop Surface Type | smooth surface |
| Hot-Surface Indicator Light | Yes |
| Center | 7" - 1500 Watts |
| Installation Type | |
| Oven Combo Approved | Yes |
| Certifications & Approvals | |
| ADA Compliant - All Brands | No |
| ANSI Certified | No |
| ETL Listed | No |
| NSF® Certified | No |
| Agency Approval(All Brands) | UL/CSA |
| UL Listed | 4-UL Certified |
| Sabbath Mode | No |
| CSA Listed | Yes |
| General Specifications | |
| Carton Width | 2.880000 |
| Carton Depth | 2.060000 |
| Carton Height | 0.580000 |
| Electrical Specifications | |
| Min Circuit Required | 40A |
| Voltage Rating | 240V / 208V 60Hz |
| Connected Load @ 240V | 9.6 / 7.2 |
| Amps @ 240 Volts | 40.0 / 34.6 |
| Connection Location | Right Rear |
| Dimensions: Cut-Out | |
| Depth | 20-1/4" - 20-1/2" |
| Width | 35-5/8" - 36-1/8" |
| Height | 5" |
Dimensions: Width: 36 3/4",l Depth to Front Corner: 21 1/2", Height (Extreme Bottom to Topside of Cooktop): 2 3/4", Height (Extreme Bottom to Underside of Cooktop): 2 5/8" Cut-Out Width: 35 5/8" Min. - 36 1/8" Max. Cut-Out Depth: 20 1/4" Min. - 20 1/2" Max. Cut-Out Height: 5" Min. Approx. Shipping Weight: 65 Lbs.
