- 9,000/8,800 BTU (Cooling)
- 12.0/12.0 E.E.R.
- 2.7 Dehumidification (pints/hr)
- 8,400/8,200 BTU Heating Capacity
- 270/235 CFM Indoor Fan (High/Low)
- 70/45 Vent CFM
- Electronic 7-Step Temperature Limiting To Prevent Overcooling or Overheating of Room
Manufacturer's Warranty: 1 year
Canadian model: AZ38H09DAB
| CAPACITY | |
| Cooling BTUH | 9000 Btu |
| Cooling E.E.R. (BTUH / Watt) | 12.0/12.0 |
| CFM Indoor Fan High | 270 |
| CFM Indoor Fan Low | 235 |
| Dehumidification (pts./hr.) | 2.7 |
| Heating - Reverse Cycle - BTUH | 8400/8200 |
| Sensible Heat Ratio at 230 Volts | 67% |
| Vent CFM | 70/45 |
| FEATURES | |
| "SmartFan" Fan Cycle | Yes |
| Auto Frost Control Monitor | Yes |
| Auto Power Recovery | Yes |
| Automatic Emergency Heat | Yes |
| Central Desk Control Compatibility | Yes |
| Control Panel Door | Yes |
| Control Type | Standard Microcomputer; Rotary Knobs |
| Discharge Grille | 2-position |
| Electric Resistance Heat Lockout | Yes |
| Fan Motor | 2 |
| Fan Speed Selections | Hi/Low Cooling 2 Fan Only Hi/Low Heating |
| Freeze Sentinel | Yes |
| Heat Pump Heat Back-Up | Resistance; Supplemental |
| Heat Sentinel | Yes |
| Louver Style | Reversible |
| Quick Heat Recovery | Yes |
| Remote Control | Compatible |
| Reverse Cycle Defrost | Yes |
| Room Occupancy Sensor | Compatible |
| Rotary Compressor | Yes |
| Solid State Thermostat Control | Yes |
| Sound Transmission Class (STC) | 29 |
| Staged Heating | 3-Stage |
| Temperature Limiting | Electronic 7-Step |
| Universal Heaters | Yes |
| Upfront Filter | Yes |
| Vent Control | 3-position |
| Weather Protected Electrical Components | Yes |
| APPEARANCE | |
| Color Appearance | Warm Gray Beige |
| WEIGHTS & DIMENSIONS | |
| Approximate Shipping Weight | 120 lb |
| Net Weight (lbs.) | 105 lb |
| Overall Depth | 13 3/4 in |
| Overall Height | 16 in |
| Overall Width | 42 in |
| POWER / RATINGS | |
| Cooling - Amperes; F.L. - Cooling | 3.8/4.1 |
| Cooling - Amperes; L.R. | 21.0 |
| Cooling - Watts | 750/735 |
| Heating - Reverse Cycle - COP | 3.6 |
| Heating - Reverse Cycle - Heater Amps | 3.2/3.5 |
| Heating - Reverse Cycle - Heater Watts (max. connected load) | 685/670 |
| Power Factor | 86/86 |
| Voltage | 230 V |
| ACCESSORIES | |
| Duct Adaptor | RAK6052 |
| Duct Extension | RAK601 |
| Exterior Architectural Louvers | RAG61(Beige); RAG62(Maple); RAG63(Bittersweet) |
| Extruded Aluminum | RAG67 |
| Insulated Wall Case | RAB71 |
| Power Connection Kit | RAK3153/3203/3303 |
| SMC Wall Case | RAB77 |
| Stamped Aluminum Exterior Rear Grille | RAG60 |
| WARRANTY | |
| Parts Warranty | Limited 1-year entire appliance Limited 5-year sealed refrigerating system |
| Labor Warranty | Limited 1-year entire appliance Limited 5-year sealed refrigerating system |
| Warranty Notes | For models produced on or after January 1, 2006 See written warranty for full details |
| Dimensions | |
|---|---|
| Height: | 16" |
| Depth: | 13 3/4" |
| Sleeve Width: | 1 |
| Sleeve Height: | 1 |
| Minimum Window Opening Width (in.): | 1 |
| Maximum Window Opening Width (in.): | 1 |
| Minimum Window Opening Height (in.): | 1 |
| Depth to Louvers (in.): | 1 |
| Interior Unit Height (Mini-split systems only): | 1 |
| Interior Unit Width (Mini-split systems only): | 1 |
| Interior Unit Depth (Mini-split systems only): | 1 |
| Weight: | 123 lbs. |
| Capacity | |
| CFM Indoor Fan High: | 270 |
| CFM Indoor Fan Low: | 235 |
| Cooling E.E.R. (BTUH / Watt): | 12.0/12.0 |
| Dehumidification (pts./hr.): | 2.7 |
| Heating - Reverse Cycle - BTUH: | 8400/8200 |
| Sensible Heat Ratio at 230 Volts: | 67% |
| Vent CFM: | 70/45 |
| Features | |
| Cooling BTUH: | 9000/8800 |
| Control Panel Door: | Yes |
| Control Type: | Standard Microcomputer; Rotary Knobs |
| Auto Power Recovery: | Yes |
| Freeze Sentinelâ„¢: | Yes |
| Heat Sentinel: | Yes |
| Louver Style: | Reversible |
| Upfront Filter: | Yes |
| Auto Frost Control Monitor: | Yes |
| Central Desk Control Compatibility: | Yes |
| Remote Control: | Compatible |
| Room Occupancy Sensor: | Compatible |
| Rotary Compressor: | Yes |
| Solid State Thermostat Control: | Yes |
| Temperature Limiting: | Electronic 7-Step |
| Weather Protected Electrical Components: | Yes |
| Vent Control: | 3-position |
| Smart Fan Fan Cycle: | Yes |
| Fan Motor: | 2 |
| Fan Speed Selections - Cooling: | Hi/Low |
| Fan Speed Selections - Fan Only: | 2 |
| Fan Speed Selections - Heating: | Hi/Low |
| Automatic Emergency Heat: | Yes |
| Electric Resistance Heat Lockout: | Yes |
| Heat Pump Heat Back-Up: | Resistance; Supplemental |
| Quick Heat Recovery: | Yes |
| Reverse Cycle Defrost: | Yes |
| Staged Heating: | 3-Stage |
| Universal Heaters: | Yes |
| Discharge Grille: | 2-position |
| Sound Transmission Class (STC): | 29 |
| Power/Ratings | |
| Power Factor: | 86/86 |
| Voltage: | 230/208 |
| Cooling - Amperes; F.L. - Cooling: | 3.8/4.1 |
| Cooling - Amperes; L.R.: | 21.0 |
| Cooling - Watts: | 750/735 |
| Heating - Reverse Cycle - COP: | 3.6 |
| Heating - Reverse Cycle - Heater Amps: | 3.2/3.5 |
| Heating - Reverse Cycle - Heater Watts (max. connected load): | 685/670 |
