GE AZ58H15DAC
Discontinued
1QL3B4
Save An Additional 5% GST Instore, Chat or Phone
Save An Additional 5% GST Instore, Chat or Phone
1QL3B4
When will I get this?

Reserve & Pick Up
FREE
Distribution Centres
Address
Units Available
Woodbridge, ON
27 Director Crt.
Winnipeg, MB
191 Elan Blvd
Burnaby, BC
8010 Winston St.
Ottawa, ON
55 Banton St.
Laval, QC
1340 Boul. Dagenais Ouest
Dartmouth, NS
315 Wilkinson Ave.
Calgary, AB
2777 23 Ave. NE
Description & Features




  • 14,700/14,400 BTU (Cooling)
  • 10.2/10.2 E.E.R.
  • 4.8 Dehumidification (pts/hr)
  • 13,400/13,200 BTU (Reverse Cycle Heat)
  • 350/330 CFM Indoor Fan (High/Low)
  • 75/45 Vent CFM
  • Corrosion-Treated Chassis Extends Life of the Unit in SeaCoast Areas
Specs
CAPACITY
Cooling BTUH 14700 Btu
Cooling E.E.R. (BTUH / Watt) 10.2/10.2
CFM Indoor Fan High 350
CFM Indoor Fan Low 330
Dehumidification (pts./hr.) 4.8
Heating - Reverse Cycle - BTUH 13,400/13,200
Sensible Heat Ratio at 230 Volts 65%
Vent CFM 75/45
FEATURES
"SmartFan" Fan Cycle Yes
Auto Frost Control Monitor Yes
Auto Power Recovery Yes
Automatic Emergency Heat Yes
Central Desk Control Compatibility Yes
Control Panel Door Yes
Control Type Highly Featured Microcomputer; Tactile touch pad with LED
Corrosion Treated Yes
Discharge Grille 2-position
Electric Resistance Heat Lockout Yes
Fan Motor 2
Fan Speed Selections Hi/Low/Auto Cooling 2 Fan Only Hi/Low/Auto Heating
Freeze Sentinel Yes
Heat Pump Heat Back-Up Resistance; Supplemental
Heat Sentinel Yes
Louver Style Reversible
Quick Heat Recovery Yes
Remote Control Compatible
Reverse Cycle Defrost Yes
Room Occupancy Sensor Compatible
Rotary Compressor Yes
Self - Diagnostics Yes
Service Indicator Yes
Solid State Thermostat Control Yes
Sound Transmission Class (STC) 29
Staged Heating 3-Stage
Temperature Limiting Electronic 7-Step
Universal Heaters Yes
Upfront Filter Yes
Vent Control 3-position
Weather Protected Electrical Components Yes
APPEARANCE
Color Appearance Warm Gray Beige
WEIGHTS & DIMENSIONS
Approximate Shipping Weight 143 lb
Net Weight (lbs.) 127 lb
Overall Depth 13 3/4 in
Overall Height 16 in
Overall Width 42 in
POWER / RATINGS
Cooling - Amperes; F.L. - Cooling 6.7/7.3
Cooling - Amperes; L.R. 38.0
Cooling - Watts 1441/1412
Heating - Reverse Cycle - COP 3.1/3.1
Heating - Reverse Cycle - Heater Amps 5.8/6.3
Heating - Reverse Cycle - Heater Watts (max. connected load) 1265/1250
Power Factor 95
Voltage 230 V
ACCESSORIES
Exterior Architectural Louvers RAG61(Beige); RAG62(Maple); RAG63(Bittersweet)
Extruded Aluminum RAG67
Insulated Wall Case RAB71
Power Connection Kit RAK3153/3203/3303
SMC Wall Case RAB77
Stamped Aluminum Exterior Rear Grille RAG60
WARRANTY
Parts Warranty Limited 1-year entire appliance Limited 5-year sealed refrigerating system
Labor Warranty Limited 1-year entire appliance Limited 5-year sealed refrigerating system
Warranty Notes For models produced on or after January 1, 2006 See written warranty for full details

Dimensions
Height: 16"
Width: 42"
Depth: 13 3/4"
Sleeve Width: 1
Sleeve Height: 1
Minimum Window Opening Width (in.): 1
Maximum Window Opening Width (in.): 1
Minimum Window Opening Height (in.): 1
Depth to Louvers (in.): 1
Interior Unit Height (Mini-split systems only): 1
Interior Unit Width (Mini-split systems only): 1
Interior Unit Depth (Mini-split systems only): 1
Weight: 150 lbs.
Appearance
Chassis: slide out
Color: warm gray beige
Control Type: touchpad
Performance
Cooling BTU: 14700
Heating BTU: 13400
Features
Fan Speed Selections: 2
Heat: heat pump
Filter Type: upfront
Technical Details
Airflow: 350
Cooling Amps: 38
Cooling EER: 10.2
Cooling Watts: 1441
Dehumidification: 4.8
Heating Amps: 6.3
Heating EER: 10.2
Heating Watts: 1265
Volts: 220
