- 17,500/17,200 BTU Cooling Capacity
- 15,700/15,500 BTU Heating Capacity
- 10.0/10.0 E.E.R. (BTU/Watt)
- Vertical Design Optimizes Floor Space
- Unique Sleeve Design Makes Units Easier to Install
- Freeze Sentinel Protects Unoccupied Rooms Against Freeze-Up
- Three-Way, Slide-Out Chassis with Specially Designed Case Makes Maintenance and Service Quick and Easy
- 17,500/17,200 BTU Cooling Capacity
- 15,700/15,500 BTU Heating Capacity
- 10.0/10.0 E.E.R. (BTU/Watt)
- Vertical Design Optimizes Floor Space - Unique Sleeve Design Makes Units Easier to Install
- Freeze Sentinel™ Protects Unoccupied Rooms Against Freeze-Up
- Three-Way, Slide-Out Chassis with Specially Designed Case Makes Maintenance and Service Quick and Easy
- Full Corrosion Treatment on Outside Coils and Other Components is Standard
Manufacturer's Warranty: 1 year
Canadian model: AZ75H18DAC
| Central Desk Control Compatibility | Yes |
| Corrosion Treated | Yes |
| Fan Speed Selections | 3 Cooling |
| Freeze Sentinel | Yes |
| Heat Pump | Yes |
| Remote Thermostat | RAK163 - Optional |
| Temperature Limiting | Yes |
| Vent Control | 3-position |
| CAPACITY | |
| Cooling BTUH (MIN) | 17200.0 Btu |
| Cooling BTUH (MAX) | 17500.0 Btu |
| CFM Indoor Fan High | 550 |
| CFM Indoor Fan Low | 475 |
| Dehumidification (pts./hr.) | 5.0 |
| Heating - Reverse Cycle - BTUH | 15700/15500 |
| WEIGHTS & DIMENSIONS | |
| Approximate Shipping Weight | 174 lb |
| Net Weight | 163 lb |
| Overall Depth | 23 1/8 in |
| Overall Height | 32 1/4 in |
| Overall Width | 23 1/8 in |
| POWER / RATINGS | |
| Voltage (MIN) | 208.0 V |
| Voltage (MAX) | 230.0 V |
| ACCESSORIES | |
| Power Connection Kit | RAK5157/5207/5307 |
| WARRANTY | |
| Parts Warranty | Limited 1-year entire appliance Limited 5-year sealed refrigerating system |
| Labor Warranty | Limited 1-year entire appliance Limited 5-year sealed refrigerating system |
| Warranty Notes | See written warranty for full details |
| Dimensions | |
|---|---|
| Height: | 32 1/4" |
| Depth: | 23 1/8" |
| Sleeve Width: | 1 |
| Sleeve Height: | 1 |
| Minimum Window Opening Width (in.): | 1 |
| Maximum Window Opening Width (in.): | 1 |
| Minimum Window Opening Height (in.): | 1 |
| Depth to Louvers (in.): | 1 |
| Interior Unit Height (Mini-split systems only): | 1 |
| Interior Unit Width (Mini-split systems only): | 1 |
| Interior Unit Depth (Mini-split systems only): | 1 |
| Weight: | 163 lbs. |
| Capacity | |
| CFM Indoor Fan High: | 550 |
| CFM Indoor Fan Low: | 475 |
| Dehumidification (pts./hr.): | 5.0 |
| Heating - Reverse Cycle - BTUH: | 15,700/15,500 |
| Features | |
| Cooling BTUH: | 17500/17200 |
| Corrosion Treated: | Yes |
| Freeze Sentinelâ„¢: | Yes |
| Central Desk Control Compatibility: | Yes |
| Remote Thermostat: | RAK163 - Optional |
| Temperature Limiting: | Yes |
| Heat Pump: | Yes |
| Power/Ratings | |
| Voltage: | 230/208 |
Owner's Manual (AZ75H18DAC-owners-manual-canada.pdf)
