Manufacturer's Warranty: 1 year
UPC: 084691822943
EAN: 0084691822943
FILTER | |
App Filter - Cabinet Width | Cooking 30 in. (Standard) |
App Filter - Cooktop Type | Continuous Grates |
App Filter - Fuel Type | Gas |
App Filter - Control Type | Rotary knobs |
APPEARANCE | |
Color Appearance | Stainless Steel |
Cooktop Burner Grate Color | Matte Black |
Control Knobs | Dishwasher Safe Stainless Steel Appearance |
POWER / RATINGS | |
Burner BTU Ratings (000's/BTU) - LP Gas | (1) 15.0; (1) 12.0; (1) 9.5; (1) 5.0 |
Burner BTU Ratings (000's/BTU) - Natural Gas | (1) 15.0; (1) 12.0; (1) 9.5; (1) 5.0 |
Electrical Requirements | 120V |
Volts/Hertz/Amps | 120V; 60Hz; 5A |
WARRANTY | |
Parts Warranty | Limited 1-year entire appliance |
Warranty Notes | See written warranty for full details |
Labor Warranty | Limited 1-year entire appliance |
ACCESSORIES | |
Stainless Steel Cleaner | Included |
WEIGHTS & DIMENSIONS | |
Overall Height | 4.75 in |
Cutout Depth (in) | 19 5/8 in |
Cabinet Width | 30 in |
Approximate Shipping Weight | 44 lb |
Overall Width | 30 in |
Net Weight | 39 lb |
Cutout Width (in) | 28.5 |
Overall Depth | 21 in |
FEATURES | |
Cooktop Burner Type | 4 Sealed |
Valves (Degree of Turn) | 270 |
Burner - Right Rear | 12,000 BTU |
Burner - Right Front | 9,500 BTU |
Fuel Type | Natural Gas |
Power Boil Burner | Yes |
Control Location | Right Side |
Cooktop Type | Continuous Grates |
Ignition System | Electronic |
Cooktop Surface | Deep Stainless Steel |
Burner - Left Rear | 5,000 BTU |
Control Type | Knob |
Cooktop Burner Grate Material | Standard Cast |
Cooktop Burner Grate Features | Continuous Grates Dishwasher Safe |
Burner - Left Front | 15,000 BTU Power Boil |
Product Type | Cooktop |
ADA Compliant | Yes |
