Replacing a similar cooktop from GE or another brand? GE cooktops are guaranteed for an exact fit to make replacement easy. See offer criteria and details
Deep-recessed cooktop
Contains spills for quick and easy cleaning
Sealed cooktop burners
Keep spillover contained on cooktop, making cleaning quick and easy
17,000 BTU Power Boil burner
Delivers intense heat for fast boiling
Precise Simmer burner
Delivers a low setting of 140 degrees
White LED backlit knobs
Indicate when burners are on so you don't forget
Control lock capability
Protects against unintended activation
Matte black heavy-cast grates
Premium cast-iron offers superior performance
- Fit Guarantee
- Replacing a similar cooktop from GE or another brand? GE cooktops are guaranteed for an exact fit to make replacement easy. See offer criteria and details
- Deep-recessed cooktop
- Contains spills for quick and easy cleaning
- Sealed cooktop burners
- Keep spillover contained on cooktop, making cleaning quick and easy
- 17,000 BTU Power Boil burner
- Delivers intense heat for fast boiling
- Precise Simmer burner
- Delivers a low setting of 140 degrees
- White LED backlit knobs
- Indicate when burners are on so you don't forget
- Control lock capability
- Protects against unintended activation
- Matte black heavy-cast grates
- Premium cast-iron offers superior performance
- Deep-Recessed Cooktop
Contains spills for quick and easy cleaning - Sealed cooktop burners
Keep spillover contained on cooktop, making cleaning quick and easy - 17,000 BTU Power Boil Burner
Delivers intense heat for fast boiling - Precise Simmer burner
Delivers a low setting of 140 degrees - White LED backlit knobs
Indicate when burners are on so you don't forget
Manufacturer's Warranty: 1 year
Canadian model: PGP976SETSS
Canadian UPC: 084691232919
EAN: 0084691232919
| FILTER | |
| App Filter - Control Type | Rotary knobs |
| App Filter - Cooktop Type | Continuous Grates |
| App Filter - Cabinet Width | Cooking 36 in. |
| App Filter - Fuel Type | Gas |
| APPEARANCE | |
| Control Knobs | Dishwasher Safe Stainless Steel Appearance (Weighted) White LED Backlit |
| Color Appearance | Stainless Steel |
| POWER / RATINGS | |
| Burner BTU Ratings (000's/BTU) - LP Gas | (1) 14.0; (1) 10.0; (2) 9.1; (1) 5.0 |
| Burner BTU Ratings (000's/BTU) - Natural Gas | (1) 17.0; (1) 11.0; (2) 9.1; (1) 5.0 |
| Volts/Hertz/Amps | 120V; 60Hz; 5A |
| WARRANTY | |
| Warranty Notes | See written warranty for full details |
| Parts Warranty | Limited 1-year entire appliance |
| Labor Warranty | Limited 1-year entire appliance |
| ACCESSORIES | |
| Stainless Steel Cleaner | Included |
| LP Conversion Kit | Included |
| WEIGHTS & DIMENSIONS | |
| Net Weight | 49.0 |
| Overall Depth | 21.0 |
| Cutout Dimensions (Width x Depth) (In.) | 33-7/8 x 19-1/8 |
| Overall Width | 36.0 |
| Overall Height | 3.25 |
| Approximate Shipping Weight | 54.0 |
| Cabinet Width | 36.0 |
| FEATURES | |
| Burner - Right Front | 11,000 BTU |
| Burner - Left Rear | 9,100 BTU |
| Cooktop Burner Type | 5 Sealed |
| Burner - Right Rear | 5,000 BTU Precise Simmer |
| Cooktop Burner Grate Features | Continuous Grates Dishwasher Safe Matte Black Self-Clean |
| Valves (Degree of Turn) | 270 |
| Cooktop Control Features | Child Lock |
| Fuel Type | Natural Gas (factory set) |
| Burner - Center | 17,000 BTU Power Boil |
| Cooktop Surface | Deep Stainless Steel |
| Burner - Left Front | 9,100 BTU |
| Cooktop Burner Grate Material | Heavy Cast |
| Control Type | Manual Simmer (1-9) Hi |
| Ignition System | Electronic |
| Control Location | Front Center |
|
Features |
|
|
Cooktop Burner Type: |
5 Sealed |
|
Ignition System: |
Electronic |
|
All-Purpose Burners: |
(2) 9,100 BTU |
|
Dual Flame Stacked Burners: |
(1) 17,000 BTU |
|
High Output Burner: |
(1) 11,000 BTU |
|
PowerBoil Burner: |
(1) 17,000 BTU |
|
Control Type: |
Manual; Simmer (1-9) Hi |
|
Child Lock: |
Yes |
|
Control Location: |
Front Center |
|
Continuous Grates: |
Yes |
|
Dishwasher Safe Grates: |
Yes |
|
Grates Color: |
Matte Black |
|
Self-Clean Grates: |
Yes |
|
Cooktop Burner Grate Material: |
Heavy Cast |
|
Fuel Type: |
Natural Gas (Factory Set) |
|
Valves (Degree Of Turn): |
270° |
|
ADA Compliant: |
Yes |
|
Power / Ratings |
|
|
Burner BTU Ratings - LP Gas: |
(1) 14,000; (1) 10,000; (2) 9,100; (1) 5,000 BTU's |
|
Burner BTU Ratings - Natural Gas: |
(1) 17,000; (1) 11,000; (2) 9,100; (1) 5,000 BTU's |
|
Volts/Hertz/Amps: |
120V; 60Hz; 5A |
|
LP Conversion Kit: |
Included |
|
Warranty |
|
|
Parts Warranty: |
Limited 1-Year Entire Appliance |
|
Labor Warranty: |
Limited 1-Year Entire Appliance |
|
Warranty Notes: |
See Written Warranty For Full Details |
|
Dimensions and Weights |
|
|
Overall Width: |
36" |
|
Overall Depth: |
20 3/4" |
|
Overall Height: |
3 1/4" |
|
Cutout Width: |
33 7/8" |
|
Cutout Depth: |
19 1/8" |
|
Net Weight: |
49 Lbs. |
|
Approx. Shipping Weight: |
54 Lbs. |
GE Fits! Program Details (PGP976SETSS-ge-fits--program-details-canada.pdf)
