Commercial-Type Cooking Power
- Gas 36" wide cooktop
- Five sealed burners with aluminum flame ports and porcelain/cast-iron caps
- Left front - 15,000 BTU high/1,700 BTU low
- Left rear - 4,000 BTU high/1,000 BTU low
- Center - 9,000 BTU high/1,300 BTU low
- Right rear - 12,000 BTU high/1,700 BTU low
- Right front - 12,000 BTU high/1,700 BTU low
- Automatic electric spark ignition/re-ignition; burners light at any position on the knob and re-light if extinguished, even at the lowest setting
Easy Operation and Cleanup
- One-piece, extremely durable steel top
- Separate spill collection areas; each area holds up to 1-1/2 quarts of liquid spillover
- Permanently sealed burners - spills cannot enter burner box
- Durable, yet elegant knobs with child-proof, push-to-turn safety feature
- Soft-touch, slip-proof rubber grips for easy handling
- Customer-removable knobs, grates, and burners/caps
- Overall/burner box dimensions designed to fit the majority of similarly sized cooktop cutouts
Exclusive Finishes
- Available in Stainless Steel (SS), Black (BK), and White (WH)
Warranty Highlights*
- One-year full - complete unit
- Five-year limited - surface burners
- Lifetime limited - stainless steel exterior
- Ninety-day limited - cosmetic parts such as glass, painted items and decorative items
*Warranty valid on Viking products shipped within the United States and Canada
Model Number
- DGVU260-5B - 36" wide cooktop
- High Performance Commercial-Type Burners
- Automatic Electric Spark Ignition
- Permanently Sealed Burners
- Easy Operation And Cleanup
Manufacturer's Warranty: 1 year
Canadian model: DGVU2605BSS
| Burner Ratings | |
| Left Front: | 15,000 Nat./LP BTU (4.4 Nat./LP kw) |
| Left Fear: | 4,000 Nat./LP BTU (1.0 Nat./LP kw) |
| Center Front/Rear: | 9,000 Nat./LP BTU (2.6 Nat./LP kw) |
| Right Front: | 12,000 Nat./LP BTU (3.5 Nat./LP kw) |
| Right Rear: | 12,000 Nat./LP BTU (3.5 Nat./LP kw) |
| Others | |
| Gas Requirements: | Accepts standard residential 1/2" (1.3 cm) I.D. gas service line. Shipped natural; gas regulator and orifice spuds are supplied with the product. |
| Electrical Requirements: | 120 VAC/60 Hz; 4 Ft. (121.9 cm), 3-Wire Cord with Grounded 3-Prong Plug Attached To Product |
| Maximum Amp Usage: | 2.0 Amps |
| Approx. Shipping Weight: | 60 Lbs. (27.0 kg) |
| Dimensions | |
| Overall Width: | 36 3/4" (93.3 cm) |
| Overall Depth: | 21" (53.5 cm) |
| Overall Height: | 4" (10.2 cm) |
| Cutout Width: | 34 1/2" (87.6 cm) Min. to 35" (88.9 cm) Max. |
| Cutout Depth: | 19" (48.3 cm) Min. to 19 5/8" (49.8 cm) Max. |
| Cutout Height: | 2 13/16" (7.2 cm) |
Specs (1 MB) (DGVU2605BSS-specs-canada.pdf)
