Zephyr Breeze I Series AK1124S Under Cabinet Range Hood 24 in with 250 CFM Internal Blower, 3 Speed Slide Controls, 2 Incandescent Lamps and Recirculating Option
Breeze I, UC, 24", SS, 250 CFM
- Value driven
- Low-profile body
- Low-profile body for a minimalist appearance.
- Extra-wide mesh filters
- High quality mesh filters with an increased width for improved capture and performance.
- Optional Ductless Recirculating Kit
- Ductless recirculating kit used when venting air outside your home is not possible. Smoke and odors pass through charcoal filters allowing purified air to be reintroduced into the kitchen.
- Multiple color options
- Multiple colors available to match your kitchen decor.
Manufacturer's Warranty: 1 year
Canadian model: AK1124S
Canadian UPC: 646328112430
EAN: 0646328112430
| Brand | Zephyr |
| Manufacturer | Zephyr |
| Category | Range Hood |
| Sub-Category | Under Cabinet |
| Vent Type | Convertible |
| UPC | 646328112430 |
| GTIN | 00646328112430 |
| Country of Origin | Taiwan |
| Model Group | AK11 |
| Model Name | Breeze I Under-Cabinet |
| Collection | Core Collection |
| Replacement Model | AK1124BS |
| Blower Included | Yes |
| Internal Blower 1 CFM | 250 |
| Internal Blower 1 Min. Sones | 1.8 |
| Internal Blower 1 Max Sones | 3.5 |
| Minimum CFM | 150 |
| Installation Type | Under Cabinet |
| Installation Type | Under Cabinet |
| For Outdoor Use | No |
| Color | Stainless Steel |
| Controls Type | Mechanical Slide |
| Blower Speeds | 3 |
| Automatic Delay-Off | No |
| Clean Air Function | No |
| Lighting Type | Halogen |
| Lights Quantity | 2 |
| Watts Per Bulb | 35 |
| Lights Levels | 2 |
| Grease Filter Type | Mesh |
| Compatible Mesh or Baffle Filter Part Number | 50200013 |
| Duct Discharge | Vertical or Horizontal |
| Duct Size; Horizontal; IN | 3.25 x 10 |
| Duct Size; Vertical; IN | 3.25 x 10 |
| Mounting Height Above Cooktop; IN | 24 - 32 |
| Voltage | 120 |
| Maximum Amperage | 1.3 |
| ADA Compliant | No |
| Warranty Parts / Labor | 3 / 1 |
| Compatible Appliances | 0AK11-21001, Z0B0040, 0AK11-20001 |
| Bluetooth Connected | No |
| Wi-Fi Connected | No |
| Remote Included | No |
| Remote Optional | No |
| Energy Star Certified | No |
| Alexa & Google Home Compatible | No |
| CEC Title 20 Compliant | Yes |
| Primary Material | Stainless Steel |
| Wattage | 156 |
| Certification | UL |
| Nominal Width; IN | 24 |
| Net Width; IN | 23.9375 |
| Net Depth; IN | 20.25 |
| Net Height; IN | 5.5 |
| Weight; LBS | 17 |
| Ceiling Height Minimum | 8 ft. |
| Ceiling Height Maximum | 12 ft. |
| Shipping Length; IN | 27.95 |
| Shipping Width; IN | 9.33 |
| Shipping Height; IN | 24.53 |
| Shipping Weight; LBS | 22.1 |
| Shipping Method | Small Parcel |
| Freight Class | 175 |
| Duct Type | Vertical |
| Duct Type | Vertical |
| Dimensions | |
| Height: | 5 1/2" |
| Width: | 24" |
| Depth: | 20 5/64" |
| Performance | |
| CFM: | 250 |
| Sones (Min-Max): | 1.5 - 3.5 |
| Features & Accessories | |
| Aluminum Filters: | 2 |
| Controls: | Slider |
| Speed Levels: | 3 |
| Lighting (Standard Incandescent): | 40R16 |
| Lighting (Optional Halogen): | PAR20 |
| Dual Level Lighting: | Yes |
| Delay Off: | No |
| Duct Specifications | |
| Ducting: | 3-Way |
| Option 1 (Vertical): | 3 1/4" x 10" |
| Option 2 (Rear Horizontal): | 3 1/4" x 10" |
| Option 3: | Recirculating (Requires kit - 0AK11-21001) |
| Accessories | |
| Recirculating Kit: | 0AK11-21001 |
| Aluminum Replacement Filters: | 0AK11-22002 |
| Carbon Filter: | 0AK11-20001 |
