Zephyr AK6500BB
Discontinued
AFBU20
Why Buy This at CAS?
Free In Home Delivery*
Cash-back
Up to 2% cash-back when paying by Visa® or Mastercard®!*
Custom Advanced Installation Services
Reserve & Pick Up
Interior Designer Discounts
Flexiti Financing as low as $39.34 for 18 months
Ratings & Reviews
Similar Colours and Options
AK6500BBS
AK6500BBS
Black Stainless Steel
AK6500BS
AK6500BS
Stainless Steel
AK6500BW
AK6500BW
White
AFBU20
When will I get this?

Why Buy This at CAS?
Free In Home Delivery*
Cash-back
Up to 2% cash-back when paying by Visa® or Mastercard®!*
Custom Advanced Installation Services
Reserve & Pick Up
Interior Designer Discounts
Flexiti Financing as low as $39.34 for 18 months
Description & Features
Zerphyr's Essentials Power Collection - Cyclone Under-Cabinet Ventilation Hood
Modern, clean lines provide a perfect complement to any interior, while the centrifugal blower liquefies cooking residue without complex filters to make clean-up a snap.
Cyclone, UC, 30", Blk, 600 CFM
  • 600 CFM Internal Blower
  • Horizontal or Vertical Venting Options
  • Mechanical Slide Controls
  • 3 Speed Level
  • 2 Halogen Lights (35W) with 2 Lighting Levels
  • 2 Removable Safety Grills
  • Self Cleaning Filterless Centrifugal Blower System
  • The centrifugal blower system automatically liquefies cooking residue in its internal housing.
  • All hoods are equipped with dishwasher safe residue cups to collect cooking residue during the self cleaning function.

Manufacturer's Warranty: 1 year

Canadian model: AK6500BB

Canadian UPC: 646328004568

EAN: 0646328004568

Specs
Brand Zephyr
Manufacturer Zephyr
Category Range Hood
Sub-Category Under Cabinet
Vent Type Ducted
UPC 646328004568
GTIN 00646328004568
Country of Origin Taiwan
Model Group AK65-B
Model Name Cyclone Under-Cabinet
Collection Core Collection
Replacement Model AK6500CB
Blower Included Yes
Internal Blower 1 CFM 600
Internal Blower 1 Min. Sones 1.5
Internal Blower 1 Max Sones 5
Minimum CFM 290
Installation Type Under Cabinet
Installation Type Under Cabinet
For Outdoor Use No
Color Black
Controls Type Mechanical Slide
Blower Speeds 3
Automatic Delay-Off No
Clean Air Function No
Lighting Type Halogen
Lights Quantity 2
Watts Per Bulb 35
Lights Levels 2
Grease Filter Type Filter-less
Duct Discharge Vertical or Horizontal
Duct Size; Horizontal; IN 3.25 x 10
Duct Size; Vertical; IN 6, 3.25 x 10
Mounting Height Above Cooktop; IN 24 - 32
Voltage 120
Maximum Amperage 2.4
ADA Compliant No
Warranty Parts / Labor 10 / 1
Compatible Appliances MUA006A, Z0B0040
Bluetooth Connected No
Wi-Fi Connected No
Remote Included No
Remote Optional No
Energy Star Certified No
Alexa & Google Home Compatible No
CEC Title 20 Compliant Yes
Primary Material Steel
Wattage 288
Certification UL
Nominal Width; IN 30
Net Width; IN 29.75
Net Depth; IN 22.25
Net Height; IN 6.375
Weight; LBS 28.8
Ceiling Height Minimum 8 ft.
Ceiling Height Maximum 12 ft.
Shipping Length; IN 9.76
Shipping Width; IN 32.68
Shipping Height; IN 27.17
Shipping Weight; LBS 35.5
Shipping Method Small Parcel
Freight Class 150
Duct Type Vertical
Duct Type Vertical
Blower Specifications
CFM:
290 - 600
Sones:
1.5 - 5
Vertical Venting:
6" Round, or 3 1/4" x 10"
Horizontal Venting:
3 1/4" x 10"
Power Requirements:
120V/60Hz at Max. 2.4 Amps
Warranty
Parts:
10 Years
Labor:
1 Year
Dimensions
Width:
29 3/4"
Depth:
22 1/4"
Height:
6 3/8"
Mounting Height:
24" - 32" (w/ 36" tall cooking surface)
