Zephyr Power Willow Series AK8800AG Outdoor Cabinet Insert Power Pack 30 in with 1000 CFM Dual Internal Blower, 2 Halogen Lights, 2-Speed Marine Grade Rocker Controls, Baffle Filters
Willow, Outdoor Power Pack, 29-13/16", Gray, 1000 CFM
- Rocker switch Marine Grade Controls
- Single Level Lighting
- 2 Speed Levels
- 2 Halogen Lights
- 2 Stainless Steel Baffle Filters
Manufacturer's Warranty: 1 year
Canadian model: AK8800AG
Canadian UPC: 646328000560
EAN: 0646328000560
| Brand | Zephyr |
| Manufacturer | Zephyr |
| Category | Range Hood |
| Sub-Category | Insert |
| Vent Type | Ducted |
| UPC | 646328000560 |
| GTIN | 00646328000560 |
| Country of Origin | Taiwan |
| Model Group | AK88 |
| Model Name | Willow |
| Collection | Pro Collection |
| Blower Included | Yes |
| Internal Blower 1 CFM | 1000 |
| Internal Blower 1 Min. Sones | 3.5 |
| Internal Blower 1 Max Sones | 8 |
| Minimum CFM | 500 |
| Installation Type | Insert |
| Installation Type | Insert |
| For Outdoor Use | Yes |
| Color | Silver |
| Controls Type | Rocker |
| Blower Speeds | 2 |
| Automatic Delay-Off | No |
| Clean Air Function | No |
| Lighting Type | Halogen |
| Lights Quantity | 2 |
| Watts Per Bulb | 35 |
| Lights Levels | 1 |
| Grease Filter Type | Pro baffle |
| Compatible Mesh or Baffle Filter Part Number | 50210010 |
| Duct Discharge | Vertical |
| Duct Size; Horizontal; IN | N/A |
| Duct Size; Vertical; IN | 8 |
| Mounting Height Above Cooktop; IN | 30 - 36 |
| Voltage | 120 |
| Maximum Amperage | 5.95 |
| ADA Compliant | No |
| Warranty Parts / Labor | 3 / 1 |
| Compatible Appliances | AK0886AS, AK0886BS, AK0882AS, AK0882BS, AK0888AS, AK0888BS, Z0B0040 |
| Bluetooth Connected | No |
| Wi-Fi Connected | No |
| Remote Included | No |
| Remote Optional | No |
| Energy Star Certified | No |
| Alexa & Google Home Compatible | No |
| CEC Title 20 Compliant | Yes |
| Primary Material | Steel |
| Wattage | 720 |
| Certification | UL |
| Nominal Width; IN | 30 |
| Net Width; IN | 29.8125 |
| Net Depth; IN | 15.8125 |
| Net Height; IN | 11.4375 |
| Weight; LBS | 39.4 |
| Ceiling Height Minimum | 8 ft. |
| Ceiling Height Maximum | 12 ft. |
| Shipping Length; IN | 34.25 |
| Shipping Width; IN | 16.54 |
| Shipping Height; IN | 21.26 |
| Shipping Weight; LBS | 46.3 |
| Shipping Method | Small Parcel |
| Freight Class | 150 |
| Duct Type | Vertical |
| Duct Type | Vertical |
| Dimensions | |
| Width: | 29 13/16" |
| Height: | 16 7/16" |
| Depth: | 15 13/16" |
| Cutout Width: | 26 1/16" |
| Cutout Depth: | 14 3/4" |
| Performance | |
| Dual Internal Blower: | 1000 CFM |
| Sones: | 8 |
| Features | |
| Marine Grade Controls: | Rocker Switch |
| Speed Levels: | 2 |
| Auto-Delay Off: | No |
| Lighting: | Halogen, 35W x 2 |
| Dual-Level Lighting: | No |
| Filters: | Baffle x2 |
| Recirculating: | No |
| Duct Specifications | |
| Vertical: | 8" |
| AC Input: | 120V - 60Hz |
| AC Power (Hood Only): | Max 710W, 5.95 Amps |
| Optional Accessories | |
| Liner, 36": | AK0886AS |
| Liner, 42": | AK0882AS |
| Liner, 48": | AK0888AS |
| Liner, 54": | AK0884AS |
| Liner, 60": | AK0880AS |
